GIDINGS&LEWIS  M.1302.5408输入输出模块 PDF资料

1.产 品 资 料 介 绍：

GIDINGS&LEWIS M.1302.5408 输入输出模块

一、产品概述

M.1302.5408 是 Giddings & Lewis 控制系统中的 数字量输入/输出模块，用于实现工业自动化系统中控制器与现场设备之间的信号交互。该模块可同时处理多路输入与输出信号，实现逻辑控制、状态采集与执行命令下发。

二、技术特点

• 输入功能：支持多路数字量输入，可采集开关、传感器、限位信号等。

• 输出功能：提供多路数字量输出，可驱动继电器、电磁阀、指示灯等执行器件。

• 电压等级：通常为 24VDC，符合工业自动化标准。

• 隔离设计：输入、输出通道与系统总线隔离，提高抗干扰能力和系统稳定性。

• 状态指示：带有 LED 状态指示灯，便于现场调试和维护。

• 保护功能：具备过流和短路保护，提高模块和系统可靠性。

三、结构与安装

• 模块化设计：可直接安装在 G&L 控制机架或兼容 I/O 插槽中。

• 接线方式：采用螺丝端子或插拔式端子，便于快速接线与维护。

• 工业级构造：坚固耐用，适合长期运行在高强度工业环境。

四、应用领域

1. 数控机床

• 控制夹具、液压阀、冷却泵、限位开关等执行和检测设备。

2. 自动化生产线

• 实现装配、搬运、检测环节的逻辑控制，确保流程顺畅。

3. 机器人系统

• 输入工件到位、急停开关、位置反馈信号，输出夹具动作或辅助设备控制。

4. 包装与印刷机械

• 控制送料、切割、张力调节及设备启动/停止操作。

5. 物流与仓储设备

• 输入货物检测、传感器信号，输出输送、堆垛及分拣指令。

英文资料：

GIDINGS&LEWIS M.1302.5408 Input/Output Module

1、 Product Overview

M. 1302.5408 is a digital input/output module in Giddings&Lewis control systems, used to achieve signal interaction between controllers and field devices in industrial automation systems. This module can simultaneously process multiple input and output signals, achieving logic control, status acquisition, and command execution.

2、 Technical features

Input function: Supports multiple digital inputs, can collect switch, sensor, limit signal, etc.

Output function: Provides multiple digital outputs that can drive actuators such as relays, solenoid valves, and indicator lights.

Voltage level: typically 24VDC, in compliance with industrial automation standards.

Isolation design: Input and output channels are isolated from the system bus to improve anti-interference ability and system stability.

Status indication: Equipped with LED status indicator lights for easy on-site debugging and maintenance.

Protection function: It has overcurrent and short-circuit protection, improving the reliability of modules and systems.

3、 Structure and Installation

Modular design: can be directly installed in G&L control racks or compatible I/O slots.

Wiring method: Screw terminals or plug-in terminals are used for quick wiring and maintenance.

Industrial grade construction: sturdy and durable, suitable for long-term operation in high-intensity industrial environments.

4、 Application Fields

CNC machine tool

Control fixtures, hydraulic valves, cooling pumps, limit switches, and other execution and detection equipment.

Automatic production line

Implement logical control over assembly, handling, and inspection processes to ensure smooth workflow.

robot system

Input workpiece positioning, emergency stop switch, position feedback signal, output fixture action or auxiliary equipment control.

Packaging and Printing Machinery

Control feeding, cutting, tension adjustment, and equipment start/stop operations.

Logistics and warehousing equipment

Input cargo detection and sensor signals, output conveying, stacking, and sorting instructions.
