GIDINGS&LEWIS 502-03550-00输入模块 PDF资料
1.产 品 资 料 介 绍：
GIDINGS&LEWIS 502-03550-00 输入模块
一、产品概述
502-03550-00 是 Giddings & Lewis 控制系统中的 数字量输入模块，用于采集工业现场的开关量/状态信号，并传递给控制器进行逻辑处理。该模块常见于数控机床、自动化产线及机器人控制系统。
二、技术特点
输入通道：提供多路独立数字输入，满足多点信号采集需求。
电压等级：通常支持 24VDC 标准工业信号输入。
隔离保护：每个输入通道与系统总线隔离，增强抗干扰能力，避免现场电气噪声影响控制系统。
信号兼容性：可采集来自传感器、按钮、限位开关、继电器触点等的输入信号。
状态指示：模块带有输入状态指示灯，便于现场调试与维护。
可靠性：具备过压保护、滤波电路设计，减少误触发和干扰。
三、结构与安装
模块化设计：可直接安装在 G&L 控制机架或兼容 I/O 系统中。
接线方式：采用标准端子接口，支持快速接线与维护。
工业级构造：坚固耐用，适合长期运行在复杂工业环境下。
英文资料：
GIDINGS&LEWIS 502-03550-00 Input Module
1、 Product Overview
502-03550-00 is a digital input module in the Giddings&Lewis control system, used to collect switch/status signals from industrial sites and transmit them to the controller for logical processing. This module is commonly used in CNC machine tools, automated production lines, and robot control systems.
2、 Technical features
Input channel: Provides multiple independent digital inputs to meet the requirements of multi-point signal acquisition.
Voltage level: Usually supports 24VDC standard industrial signal input.
Isolation protection: Each input channel is isolated from the system bus to enhance anti-interference capability and avoid on-site electrical noise affecting the control system.
Signal compatibility: It can collect input signals from sensors, buttons, limit switches, relay contacts, etc.
Status indication: The module is equipped with input status indicator lights for easy on-site debugging and maintenance.
Reliability: Equipped with overvoltage protection and filtering circuit design to reduce false triggering and interference.
3、 Structure and Installation
Modular design: can be directly installed in G&L control racks or compatible I/O systems.
Wiring method: Using standard terminal interfaces, supporting fast wiring and maintenance.
Industrial grade construction: sturdy and durable, suitable for long-term operation in complex industrial environments.
2.产 品 展 示
