GIDINGS&LEWIS M.1300.4981输出模块 PDF资料

1.产 品 资 料 介 绍：

GIDINGS&LEWIS M.1300.4981 输出模块

一、产品概述

M.1300.4981 是 Giddings & Lewis 控制系统中的一款 数字量输出模块，主要用于将控制器的逻辑信号转化为可驱动现场执行元件（如继电器、电磁阀、指示灯等）的电气信号。该模块常用于数控机床、自动化生产线和工业控制系统中。

二、技术特点

• 输出通道：提供多路独立数字输出，可直接驱动工业现场负载。

• 电压等级：通常支持 24VDC 输出，符合工业自动化标准。

• 输出类型：晶体管或继电器型输出，具体取决于模块配置，可实现快速开关与隔离保护。

• 隔离设计：通道之间及与控制系统之间具备电气隔离，降低干扰与故障传递。

• 状态指示：带有输出状态指示灯，便于维护与故障排查。

• 保护功能：具备过流、短路保护，提升运行可靠性。

三、结构与安装

• 标准化模块化设计，可直接安装在 G&L 控制机架或兼容的 I/O 插槽中。

• 采用可插拔端子或螺丝压线端子，便于接线与更换。

• 工业级外壳与电路板工艺，适合恶劣工况环境。

四、应用领域

1. 数控机床

• 控制冷却泵、液压阀、润滑系统、工件夹紧装置等执行部件。

2. 自动化产线

• 驱动电磁阀、气缸、传送带启动与停止，实现工艺流程控制。

3. 机器人及装配设备

• 输出控制信号至末端夹具、视觉系统照明或辅助动作设备。

4. 包装与印刷机械

• 控制切刀、输送机构、喷码装置的启停与联动。

5. 物流与仓储设备

• 驱动输送带电机控制继电器、堆垛机控制单元，实现物料搬运。

英文资料：

GIDINGS&LEWIS M.1300.4981 output module

1、 Product Overview

M. 1300.4981 is a digital output module in the Giddings&Lewis control system, mainly used to convert the logic signals of the controller into electrical signals that can drive field actuators such as relays, solenoid valves, indicator lights, etc. This module is commonly used in CNC machine tools, automated production lines, and industrial control systems.

2、 Technical features

Output channel: Provides multiple independent digital outputs that can directly drive industrial field loads.

Voltage level: typically supports 24VDC output, in compliance with industrial automation standards.

Output type: transistor or relay type output, depending on module configuration, can achieve fast switching and isolation protection.

Isolation design: Electrical isolation is provided between channels and control systems to reduce interference and fault transmission.

Status indicator: Equipped with output status indicator lights for easy maintenance and troubleshooting.

Protection function: Equipped with overcurrent and short-circuit protection to enhance operational reliability.

3、 Structure and Installation

Standardized modular design, can be directly installed in G&L control racks or compatible I/O slots.

Adopting pluggable terminals or screw pressed terminals for easy wiring and replacement.

Industrial grade casing and circuit board technology, suitable for harsh working environments.

4、 Application Fields

CNC machine tool

Control the execution components such as cooling pump, hydraulic valve, lubrication system, workpiece clamping device, etc.

automated production line

Drive solenoid valves, cylinders, and conveyor belts to start and stop, achieving process control.

Robots and assembly equipment

Output control signals to end fixtures, visual system lighting, or auxiliary motion equipment.

Packaging and Printing Machinery

Control the start stop and linkage of the cutting blade, conveying mechanism, and coding device.

Logistics and warehousing equipment

Drive the conveyor belt motor control relay and stacker crane control unit to achieve material handling.
