GIDINGS&LEWIS 502-03786-02编码器 PDF资料

1.产 品 资 料 介 绍：

GIDDINGS & LEWIS 502-03786-02 编码器

产品概述

502-03786-02 是 Giddings & Lewis 的一款 高精度旋转编码器，用于数控机床和自动化系统中检测旋转轴的位置、速度和方向。该编码器提供闭环反馈信号，与伺服驱动器及控制器配合，实现精确的运动控制和位置调节。

产品应用领域

1. 数控机床（CNC）

• 测量主轴和进给轴的位置和转速，实现高精度加工和多轴同步控制。

2. 工业自动化生产线

• 对旋转电机或传动装置进行实时位置和速度监控，确保自动化工序精准运行。

3. 机器人系统

• 作为关节伺服电机的位置反馈装置，保证动作的重复精度和路径控制。

4. 包装与印刷机械

• 监测送料轮、卷轴或张力滚筒的旋转状态，确保同步操作和加工稳定性。

5. 实验与测试平台

• 提供旋转运动的高精度测量，用于实验台、测试台和研发平台的动态分析。

产品特点

• 高精度反馈：提供微米级位置检测和高速旋转测量。

• 高速响应：能够实时输出脉冲或模拟信号，保证运动控制闭环精度。

• 工业可靠性：耐振动、防尘、防干扰，适应车间复杂环境。

• 多种输出类型：可输出增量脉冲或绝对编码信号，适应不同控制需求。

• 模块化设计：安装便捷，便于与伺服系统或控制板配合使用。

• 系统兼容性强：可与 G&L 系列伺服驱动器及控制模块无缝集成。

英文资料：

GIDINGS&LEWIS 502-03786-02 Encoder

Product Overview

502-03786-02 is a high-precision rotary encoder from Giddings&Lewis, used for detecting the position, velocity, and direction of rotating axes in CNC machine tools and automation systems. This encoder provides closed-loop feedback signals, which work in conjunction with servo drivers and controllers to achieve precise motion control and position adjustment.

Product application areas

Numerical Control Machine Tool (CNC)

Measure the position and speed of the spindle and feed axis to achieve high-precision machining and multi axis synchronous control.

Industrial automation production line

Real time position and speed monitoring of rotating motors or transmission devices to ensure precise operation of automated processes.

robot system

As a position feedback device for joint servo motors, it ensures the repeatability accuracy and path control of actions.

Packaging and Printing Machinery

Monitor the rotation status of the feeding wheel, reel, or tension drum to ensure synchronous operation and processing stability.

Experimental and testing platform

Provide high-precision measurement of rotational motion for dynamic analysis of experimental benches, testing benches, and research and development platforms.

Product Features

High precision feedback: Provides micrometer level position detection and high-speed rotation measurement.

High speed response: capable of real-time output of pulses or analog signals, ensuring closed-loop accuracy of motion control.

Industrial reliability: resistant to vibration, dustproof, anti-interference, suitable for complex workshop environments.

Multiple output types: can output incremental pulses or absolute encoded signals to meet different control requirements.

Modular design: easy to install and compatible with servo systems or control boards.

Strong system compatibility: can seamlessly integrate with G&L series servo drives and control modules.
