GIDINGS&LEWIS 502-03642-02输入分析模块 PDF资料

1.产 品 资 料 介 绍：

GIDDINGS & LEWIS 502-03642-02 输入分析模块

产品概述

502-03642-02 是 Giddings & Lewis 的一款 输入分析模块，主要用于数控机床或工业自动化系统中采集和分析各种输入信号。模块能够对来自传感器、开关或其他输入设备的信号进行实时监测、处理和传递，确保控制系统能够根据实时数据进行准确决策。

产品应用领域

1. 数控机床（CNC）

• 采集限位开关、光栅尺或主轴反馈信号，用于精确控制加工动作。

• 支持多轴同步和复杂路径控制的实时信号分析。

2. 工业自动化生产线

• 采集传感器、检测器及输入设备的状态信号，实现生产过程自动化监控。

• 用于检测工位动作、材料位置或工件状态。

3. 机器人系统

• 分析机器人关节、末端执行器及安全传感器的输入信号，实现精准运动控制。

4. 包装与印刷机械

• 对送料检测、张力传感器和工件位置传感器进行数据采集和分析。

5. 测试与研发平台

• 收集实验装置或测试设备的输入数据，提供实时监控和分析功能。

英文资料：

GIDINGS&LEWIS 502-03642-02 Input Analysis Module

Product Overview

502-03642-02 is an input analysis module from Giddings&Lewis, mainly used for collecting and analyzing various input signals in CNC machine tools or industrial automation systems. The module is capable of real-time monitoring, processing, and transmitting signals from sensors, switches, or other input devices, ensuring that the control system can make accurate decisions based on real-time data.

Product application areas

Numerical Control Machine Tool (CNC)

Collect limit switches, grating rulers, or spindle feedback signals for precise control of machining actions.

Real time signal analysis supporting multi axis synchronization and complex path control.

Industrial automation production line

Collect status signals from sensors, detectors, and input devices to achieve automated monitoring of the production process.

Used to detect workstation movements, material positions, or workpiece status.

robot system

Analyze the input signals of robot joints, end effectors, and safety sensors to achieve precise motion control.

Packaging and Printing Machinery

Collect and analyze data for feeding detection, tension sensors, and workpiece position sensors.

Testing and Development Platform

Collect input data from experimental devices or testing equipment, and provide real-time monitoring and analysis functions.

2.产      品      展      示
