GIDINGS&LEWIS 502-03518-02输出直流模块 PDF资料

1.产 品 资 料 介 绍：

GIDDINGS & LEWIS 502-03518-02 输出直流模块

产品应用领域

1. 数控机床 (CNC) 系统

• 用于 CNC 设备的伺服执行机构控制，将数字指令转换为直流信号驱动执行端。

• 实现主轴电机、进给电机的精准调节。

2. 工业自动化生产线

• 在装配、搬运和检测工位中作为电源输出单元，为执行器或控制器提供稳定直流信号。

• 提升生产线的动作协调性和效率。

3. 机器人与运动控制

• 为机器人驱动电路提供直流输出信号，实现关节或轴向的精确运动控制。

• 适合高响应和高可靠度要求的自动化机器人系统。

4. 包装与印刷机械

• 为张力控制、电机控制以及同步系统提供直流驱动信号。

• 保证高速包装、印刷过程中的稳定性。

5. 电子与半导体设备

• 在贴片机、测试机及输送机构中用作直流信号输出模块。

• 提供精密控制和快速响应，满足高精度制造工艺需求。

6. 测试与实验平台

• 在实验设备或电机测试台中，用于提供可控的直流输出信号。

• 满足研发与调试中对直流输出精度和稳定性的要求。

总结

502-03518-02 输出直流模块广泛应用于 CNC 加工、自动化生产、机器人系统、包装印刷、电子制造和测试设备 等需要 稳定直流输出与高精度控制 的领域，是工业自动化控制架构中的关键功能模块之一。

英文资料：

GIDINGS&LEWIS 502-03518-02 Output DC Module

Product application areas

Numerical Control Machine Tool (CNC) System

Used for servo actuator control of CNC equipment, converting digital instructions into DC signals to drive the execution end.

Realize precise adjustment of spindle motor and feed motor.

Industrial automation production line

As a power output unit in assembly, handling, and testing stations, it provides stable DC signals for actuators or controllers.

Improve the coordination and efficiency of production line operations.

Robots and Motion Control

Provide DC output signals for robot drive circuits to achieve precise motion control of joints or axes.

Suitable for automated robot systems with high response and reliability requirements.

Packaging and Printing Machinery

Provide DC drive signals for tension control, motor control, and synchronization systems.

Ensure stability during high-speed packaging and printing processes.

Electronic and semiconductor equipment

Used as a DC signal output module in surface mount machines, testing machines, and conveyor mechanisms.

Provide precise control and fast response to meet the requirements of high-precision manufacturing processes.

Testing and experimental platform

Used in experimental equipment or motor testing stations to provide controllable DC output signals.

Meet the requirements for DC output accuracy and stability in research and development and debugging.

summary

The 502-03518-02 output DC module is widely used in fields such as CNC machining, automated production, robot systems, packaging and printing, electronic manufacturing, and testing equipment that require stable DC output and high-precision control. It is one of the key functional modules in industrial automation control architecture.

2.产      品      展      示
