GIDINGS&LEWIS M.1017.6011中央服务板模块卡 PDF资料

1.产 品 资 料 介 绍：

GIDINGS&LEWIS M.1017.6011 中央服务板模块卡

产品概述

Giddings & Lewis M.1017.6011 中央服务板模块卡是一种核心控制与管理模块，主要用于数控系统和自动化控制系统中，承担中央数据处理、系统协调和服务功能。该模块是控制系统中的“枢纽单元”，负责与输入/输出模块、伺服驱动模块以及通信接口协同工作，确保整个系统的稳定运行。

技术参数（典型特性）

• 模块类型：中央服务板（Central Service Board Module）

• 功能定位：作为中央控制的服务单元，进行数据交换、状态监控、故障诊断与通信调度

• 接口支持：支持与多种控制卡件及伺服模块连接

• 供电电源：+5 V 直流逻辑电源（具体电流视系统配置）

• 工作环境：

• 温度范围：0 °C ~ 55 °C

• 湿度范围：5% ~ 95%，无凝露

• 设计特点：工业级电路设计，具备故障检测、冗余保护和诊断功能

应用场景

1. 数控机床控制系统

• 作为 CNC 系统中的中央单元，用于协调主轴控制、伺服进给和加工路径管理。

2. 自动化生产线

• 在装配、测试和搬运系统中，用于集中管理各模块的逻辑与通信。

3. 运动控制系统

• 与伺服驱动器、I/O 模块结合，实现多轴协调控制。

4. 工业设备集成

• 应用于包装设备、机器人控制平台、印刷机械等复杂自动化设备。

5. 系统监控与维护

• 提供系统诊断与状态监控功能，便于故障排查和维护。

英文资料：

GIDINGS&LEWIS M.1017.6011 Central Service Board Module Card

Product Overview

Giddings&Lewis M.1017.6011 Central Service Board Module Card is a core control and management module mainly used in CNC systems and automation control systems, responsible for central data processing, system coordination, and service functions. This module is the "hub unit" in the control system, responsible for working in conjunction with input/output modules, servo drive modules, and communication interfaces to ensure the stable operation of the entire system.

Technical parameters (typical characteristics)

Module type: Central Service Board Module

Functional positioning: As a centrally controlled service unit, it performs data exchange, status monitoring, fault diagnosis, and communication scheduling

Interface support: Supports connection with multiple control cards and servo modules

Power supply:+5V DC logic power supply (specific current depends on system configuration)

Work environment:

Temperature range: 0 ° C~55 ° C

Humidity range: 5%~95%, no condensation

Design features: Industrial grade circuit design with fault detection, redundant protection, and diagnostic functions

Application scenarios

Numerical Control Machine Tool Control System

As the central unit in CNC systems, it is used to coordinate spindle control, servo feed, and machining path management.

Automatic production line

In assembly, testing, and handling systems, it is used to centrally manage the logic and communication of each module.

Motion control system

Combined with servo drives and I/O modules, achieve multi axis coordinated control.

Industrial equipment integration

Applied to complex automation equipment such as packaging equipment, robot control platforms, printing machinery, etc.

System monitoring and maintenance

Provide system diagnosis and status monitoring functions for easy troubleshooting and maintenance.

2.产      品      展      示
