GIDINGS&LEWIS  502-02777-50数字化控制板 PDF资料

1.产 品 资 料 介 绍：

GIDINGS&LEWIS 502-02777-50 数字化控制板

产品概述

Giddings & Lewis 502-02777-50 是一款用于工业自动化和数控系统的数字化控制板（Digital Control Board）。它主要承担数据处理、指令逻辑运算以及外围接口的数字化管理，是 CNC 系统、运动控制器和复杂生产设备的核心组成部分。该板卡通过高速总线与其他功能模块通信，实现对伺服驱动、I/O 模块及执行机构的集中管理。

技术参数

• 类型：数字化控制板

• 功能：负责逻辑运算、程序执行及信号调度

• 处理能力：支持高速逻辑控制与数据处理（具体时钟频率随系统配置）

• 接口特性：

• 可连接 I/O 模块、伺服驱动模块和通信接口

• 支持多通道数据采集与输出

• 数据处理：具备实时任务调度功能，保障控制循环稳定

• 供电要求：+5 V 直流逻辑电源（典型电流根据系统配置在数百 mA 范围）

• 工作环境：

• 温度：0 °C ~ 55 °C

• 湿度：5% ~ 95%，无凝露

• 可靠性设计：支持过载保护、故障检测与自诊断功能

英文资料：

GIDINGS&LEWIS 502-02777-50 Digital Control Board

Product Overview

Giddings&Lewis 502-02777-50 is a digital control board used for industrial automation and numerical control systems. It mainly undertakes data processing, instruction logic operations, and digital management of peripheral interfaces, and is a core component of CNC systems, motion controllers, and complex production equipment. This board communicates with other functional modules through a high-speed bus to achieve centralized management of servo drives, I/O modules, and actuators.

Technical Specifications

Type: Digital Control Board

Function: Responsible for logical operations, program execution, and signal scheduling

Processing capability: Supports high-speed logic control and data processing (specific clock frequency varies with system configuration)

Interface features:

Can connect I/O modules, servo drive modules, and communication interfaces

Support multi-channel data acquisition and output

Data processing: equipped with real-time task scheduling function to ensure stable control loop

Power supply requirement:+5V DC logic power supply (typical current ranges from several hundred mA according to system configuration)

Work environment:

Temperature: 0 ° C~55 ° C

Humidity: 5%~95%, no condensation

Reliability design: supports overload protection, fault detection, and self diagnosis functions
