GIDINGS&LEWIS  501-04707-00伺服控制板  PDF资料

1.产 品 资 料 介 绍：

GIDDINGS & LEWIS 501-04707-00 伺服控制板

1. 产品概述

501-04707-00 是 Giddings & Lewis 用于工业自动化系统的 伺服控制板模块，专为精密控制伺服电机设计。它能接收 CPU 或控制器的指令信号，对电机进行闭环控制，实现位置、速度和扭矩的精准管理。

2. 产品应用领域

a) 精密加工设备

• 控制机床主轴及多轴联动，实现微米级加工精度。

• 管理刀具位置和加工顺序，提高加工质量和效率。

b) 自动装配系统

• 驱动自动装配机械和精密搬运装置，实现高速、精准的零件装配。

• 协调多个伺服轴的同步动作，确保装配精度。

c) 自动化检测设备

• 控制测量台或检测机械动作，保证重复定位精度和检测可靠性。

d) 轻型机器人与智能机械手

• 控制小型机器人或机械手臂的动作，实现精确运动控制和路径规划。

e) 专用工业设备

• 应用于实验室自动化设备、包装机、分拣系统或定制工业单元，实现特定动作逻辑和伺服驱动控制。

英文资料：

GIDINGS&LEWIS 501-04707-00 servo control board

1. Product Overview

501-04707-00 is a servo control board module designed by Giddings&Lewis for industrial automation systems, specifically for precision control of servo motors. It can receive instruction signals from the CPU or controller, perform closed-loop control on the motor, and achieve precise management of position, speed, and torque.

2. Product application areas

a) Precision machining equipment

Control the spindle and multi axis linkage of the machine tool to achieve micrometer level machining accuracy.

Manage tool position and machining sequence to improve machining quality and efficiency.

b) Automatic assembly system

Drive automatic assembly machinery and precision handling devices to achieve high-speed and precise component assembly.

Coordinate the synchronous actions of multiple servo axes to ensure assembly accuracy.

c) Automated testing equipment

Control the measuring table or detect mechanical movements to ensure repeat positioning accuracy and detection reliability.

d) Lightweight robots and intelligent robotic arms

Control the movements of small robots or robotic arms to achieve precise motion control and path planning.

e) Specialized industrial equipment

Applied to laboratory automation equipment, packaging machines, sorting systems, or customized industrial units to achieve specific action logic and servo drive control.

2.产      品      展      示
