GIDINGS&LEWIS 502-03840-44伺服编码器 PDF资料

1.产 品 资 料 介 绍：

GIDDINGS & LEWIS 502-03840-44 伺服编码器

1. 产品概述

502-03840-44 是 Giddings & Lewis 伺服控制系统中的反馈元件模块，属于 伺服电机配套编码器。该编码器的核心作用是将伺服电机的机械运动（转速、转角、位移）转换为电信号，实时反馈给控制器，用于实现闭环控制。

2. 技术特性

• 高分辨率：能够提供精确的位置信号与速度信号，满足数控与自动化设备的高精度要求。

• 实时反馈：作为伺服系统的闭环检测元件，保证运动过程的动态响应与稳定性。

• 接口兼容：与 G&L 控制系统及伺服驱动单元直接兼容，支持标准反馈信号输出。

• 抗干扰设计：适合工业现场环境，能抵御电磁干扰与机械振动。

• 模块化应用：通常与伺服驱动器、CPU 控制模块配合，组成完整的运动控制系统。

3. 应用领域

a) 数控机床

• 用于镗铣床、车床、加工中心，实时反馈主轴或进给伺服电机位置，实现高精度切削与定位。

b) 自动化生产线

• 应用于装配、搬运、检测设备的伺服驱动系统，提供精准位置和速度反馈。

c) 机器人系统

• 在多关节机器人中提供各关节的角度和速度反馈，保证轨迹控制与动作同步。

d) 工业过程控制

• 用于输送、卷绕、张力控制等场合，保证设备运行平稳、速度精准。

e) 物流与仓储自动化

• 应用于堆垛机、输送线伺服电机的运动控制，确保货物定位准确。

英文资料：

GIDINGS&LEWIS 502-03840-44 servo encoder

1. Product Overview

502-03840-44 is a feedback component module in the Giddings&Lewis servo control system, which belongs to the encoder supporting servo motors. The core function of this encoder is to convert the mechanical motion (speed, angle, displacement) of the servo motor into electrical signals and provide real-time feedback to the controller for closed-loop control.

2. Technical characteristics

High resolution: capable of providing accurate position and velocity signals, meeting the high-precision requirements of CNC and automation equipment.

Real time feedback: As a closed-loop detection component of the servo system, it ensures the dynamic response and stability of the motion process.

Interface compatibility: Directly compatible with G&L control systems and servo drive units, supporting standard feedback signal output.

Anti interference design: suitable for industrial site environment, able to resist electromagnetic interference and mechanical vibration.

Modular application: usually combined with servo drives and CPU control modules to form a complete motion control system.

3. Application Fields

a) CNC machine tool

Used for boring and milling machines, lathes, and machining centers to provide real-time feedback on the position of the spindle or feed servo motor, achieving high-precision cutting and positioning.

b) Automated production line

A servo drive system applied to assembly, handling, and testing equipment, providing precise position and speed feedback.

c) Robot system

Provide angle and velocity feedback for each joint in a multi joint robot to ensure trajectory control and motion synchronization.

d) Industrial Process Control

Used for conveying, winding, tension control and other occasions, ensuring smooth operation and precise speed of the equipment.

e) Logistics and Warehouse Automation

Applied to the motion control of stacker cranes and conveyor servo motors to ensure accurate positioning of goods.

2.产      品      展      示
