GIDDINGS & LEWIS 502-03657-00 I/O 驱动器

1. 产品概述

502-03657-00 属于 Giddings & Lewis PiC900 系列控制系统的 I/O 驱动模块，用于工业自动化系统中实现控制器与现场设备之间的输入/输出信号交互。它在整个控制架构中扮演“桥梁”角色，将传感器、开关、执行器等现场设备与中央处理单元连接，实现数据采集与指令输出。

2. 技术特性

• 信号接口：支持多通道数字量 I/O，能够驱动或采集开关量信号。

• 数据传输：通过 PiC900 系统背板总线与 CPU 模块通信，实时传输现场信号。

• 模块化设计：可插装在控制系统机架中，与其他 I/O 模块组合，便于扩展。

• 工业可靠性：具备抗干扰设计，适合长期在恶劣工业环境中稳定运行。

• 维护便捷：模块化更换方式，便于检修与升级。

3. 应用领域

a) 数控机床

• 用于采集机床限位开关、刀具检测信号，并控制液压阀、冷却泵、电磁装置等。

• 确保机床运行的实时性与安全性。

b) 自动化生产线

• 在装配、搬运、分拣、包装生产线上，采集传感器状态并驱动执行器。

• 实现输送带启停、气动元件控制、工件检测和信号反馈。

c) 工业过程控制

• 应用于冶金、化工、能源等行业，将现场的温度开关、压力开关、流量信号采集到控制系统。

• 同时驱动电磁阀、马达启动器等设备，实现过程自动化。

d) 机器人与运动系统

• 在机器人控制中用于采集位置信号、急停开关，输出控制命令到伺服驱动或末端执行器。

• 保证多关节运动和外部设备的协调。

e) 物流与仓储自动化

• 应用于自动仓储和堆垛机，采集货位检测信号，控制提升机构和搬运装置。

英文资料：

GIDINGS&LEWIS 502-03657-00 I/O Drivers

1. Product Overview

502-03657-00 belongs to the Giddings&Lewis PiC900 series control system's I/O driver module, which is used in industrial automation systems to achieve input/output signal interaction between controllers and field devices. It plays the role of a "bridge" in the entire control architecture, connecting field devices such as sensors, switches, and actuators with the central processing unit to achieve data acquisition and instruction output.

2. Technical characteristics

Signal interface: Supports multi-channel digital I/O, capable of driving or collecting switch signals.

Data transmission: Communicate with the CPU module through the PiC900 system backplane bus to transmit real-time on-site signals.

Modular design: Can be plugged into the control system rack and combined with other I/O modules for easy expansion.

Industrial reliability: Equipped with anti-interference design, suitable for long-term stable operation in harsh industrial environments.

Convenient maintenance: modular replacement method, easy to repair and upgrade.

3. Application Fields

a) CNC machine tool

Used to collect machine limit switches, tool detection signals, and control hydraulic valves, cooling pumps, electromagnetic devices, etc.

Ensure the real-time and safe operation of the machine tool.

b) Automated production line

Collect sensor status and drive actuators on assembly, handling, sorting, and packaging production lines.

Implement conveyor belt start stop, pneumatic component control, workpiece detection, and signal feedback.

c) Industrial Process Control

Applied in industries such as metallurgy, chemical engineering, and energy, it collects temperature switches, pressure switches, and flow signals from the site into the control system.

Simultaneously driving equipment such as solenoid valves and motor starters to achieve process automation.

d) Robots and Motion Systems

Used in robot control to collect position signals, emergency stop switches, and output control commands to servo drives or end effectors.

Ensure coordination between multi joint movements and external devices.

e) Logistics and Warehouse Automation

Applied to automatic warehousing and stacker cranes, collecting location detection signals, controlling lifting mechanisms and handling devices.
