GIDINGS&LEWIS   M.1300.7167总线扩展模块 PDF资料

1.产 品 资 料 介 绍：

GIDDINGS & LEWIS M.1300.7167 总线扩展模块

产品应用领域

1. 产品概述

GIDDINGS & LEWIS M.1300.7167 是一款总线扩展模块，主要用于将机床或运动控制系统接入工业现场总线网络。该模块通常作为 PROFIBUS 主站 使用，可以连接多个从站设备，实现分布式控制与数据交换。

2. 技术特性

• 提供标准化的 PROFIBUS 接口，具备良好的兼容性。

• 支持多节点接入，最大可管理约 125 个从站。

• 可通过专用配置工具进行参数设定，并与控制器映射逻辑信号。

• 支持 RS-232 接口进行模块配置，方便与控制系统对接。

3. 应用领域

a) 数控机床与加工中心

• 用于大型数控镗铣床、车床、加工中心的控制系统扩展，方便连接分布式 I/O 和驱动单元。

• 能够实现多轴同步控制和现场设备的数据交换，提高机床自动化水平。

b) 自动化生产线

• 应用于复杂装配线和柔性制造系统，将多个传感器、执行器通过 PROFIBUS 网络集中管理。

• 通过总线方式简化布线，提升系统扩展性。

c) 工业过程控制

• 在石化、能源、冶金等行业中，将过程控制设备（阀门、检测单元、现场控制站）集成到同一网络中，便于集中监控与协调。

d) 分布式 I/O 系统

• 适合在需要远距离或分布式布置的环境下，将分散的 I/O 模块通过总线连接到中央控制器。

• 减少传统点对点布线的复杂性，提升系统灵活性。

e) 机器人与物流自动化

• 在机器人、堆垛机、输送系统等场合，通过 PROFIBUS 网络实现驱动单元与控制系统的高效通信。

• 保证多设备协作时的实时性与稳定性。

英文资料：

GIDINGS&LEWIS M.1300.7167 Bus Expansion Module

Product application areas

1. Product Overview

GIDINGS&LEWIS M.1300.7167 is a bus expansion module primarily used to connect machine tools or motion control systems to industrial fieldbus networks. This module is typically used as a PROFIBUS master and can connect multiple slave devices to achieve distributed control and data exchange.

2. Technical characteristics

Provide standardized PROFIBUS interface with good compatibility.

Supports multi node access and can manage up to approximately 125 slave stations.

Parameters can be set through a dedicated configuration tool and mapped to logic signals with the controller.

Supports RS-232 interface for module configuration, facilitating integration with control systems.

3. Application Fields

a) Numerical Control Machine Tools and Machining Centers

Used for expanding the control system of large CNC boring and milling machines, lathes, and machining centers, facilitating the connection of distributed I/O and drive units.

It can achieve multi axis synchronous control and data exchange of on-site equipment, improving the automation level of machine tools.

b) Automated production line

Applied to complex assembly lines and flexible manufacturing systems, multiple sensors and actuators are centrally managed through a PROFIBUS network.

Simplify wiring through bus mode and enhance system scalability.

c) Industrial Process Control

In industries such as petrochemicals, energy, metallurgy, etc., integrating process control equipment (valves, detection units, on-site control stations) into the same network facilitates centralized monitoring and coordination.

d) Distributed I/O System

Suitable for environments that require remote or distributed deployment, connecting dispersed I/O modules to a central controller through a bus.

Reduce the complexity of traditional point-to-point routing and enhance system flexibility.

e) Robots and Logistics Automation

Efficient communication between drive units and control systems is achieved through PROFIBUS networks in applications such as robots, stackers, and conveyor systems.

Ensure real-time performance and stability when multiple devices collaborate.
