GIDINGS&LEWIS  M.1301.2073图形触摸屏 PDF资料

1.产 品 资 料 介 绍：

一、产品概述

GIDDINGS & LEWIS M.1301.2073 图形触摸屏是一款专为工业自动化和数控机床设计的人机界面（HMI）设备。它通过直观的图形界面，提供操作、监控和控制功能，使操作人员能够实时查看设备状态、调整参数并管理生产流程。该触摸屏结合高分辨率显示和触控操作，提升系统可视化和操作便利性。

二、技术参数（典型特性）

• 型号：M.1301.2073

• 类型：图形触摸屏（HMI）

• 显示特性：高分辨率彩色液晶显示

• 触控方式：电阻式或电容式触控，支持多点触控（根据具体配置）

• 接口：支持以太网、串口、USB 等工业通信接口

• 操作系统/固件：工业级操作系统，支持自定义界面和控件

• 安装方式：面板嵌入式或支架安装，便于设备集成

• 工业适应性：耐高温、高湿、抗振动及电磁干扰

三、应用场景

1. 数控机床（CNC）

• 实时显示机床状态、加工程序及报警信息

• 提供参数调整、程序启动/停止及操作控制界面

2. 自动化生产线

• 监控机械臂、输送设备和分拣系统

• 可操作多设备协调控制和生产流程管理

3. 包装与印刷机械

• 显示生产节拍、设备状态和产品质量信息

• 支持操作员实时调节生产参数

4. 实验与测试设备

• 提供数据监控、实验状态显示及参数设置界面

• 支持实验过程可视化与结果记录

5. 工业自动化监控系统

• 作为系统人机交互接口，实现设备管理、报警监控及数据查看

• 可与控制器、PLC 或 CPU 模块无缝集成

英文资料：

1、 Product Overview

GIDINGS&LEWIS M.1301.2073 Graphic Touch Screen is a human-machine interface (HMI) device designed specifically for industrial automation and CNC machine tools. It provides operation, monitoring, and control functions through an intuitive graphical interface, enabling operators to view equipment status, adjust parameters, and manage production processes in real time. The touch screen combines high-resolution display and touch operation to enhance system visualization and operational convenience.

2、 Technical parameters (typical characteristics)

Model: M.1301.2073

Type: Graphic Touch Screen (HMI)

Display feature: High resolution color LCD display

Touch mode: resistive or capacitive touch, supports multi touch (depending on specific configuration)

Interface: Supports industrial communication interfaces such as Ethernet, serial port, USB, etc

Operating System/Firmware: Industrial grade operating system, supporting custom interfaces and controls

Installation method: panel embedded or bracket installation, convenient for device integration

Industrial adaptability: resistant to high temperature, high humidity, vibration and electromagnetic interference

3、 Application scenarios

Numerical Control Machine Tool (CNC)

Real time display of machine status, machining program, and alarm information

Provide parameter adjustment, program start/stop, and operation control interface

Automatic production line

Monitoring robotic arms, conveying equipment, and sorting systems

Operable multi device coordinated control and production process management

Packaging and Printing Machinery

Display production pace, equipment status, and product quality information

Support operators to adjust production parameters in real-time

Experimental and testing equipment

Provide data monitoring, experimental status display, and parameter setting interface

Support visualization of experimental processes and recording of results

Industrial Automation Monitoring System

As a system human-computer interaction interface, it realizes device management, alarm monitoring, and data viewing

Seamless integration with controllers, PLCs, or CPU modules
