GIDDINGS & LEWIS  502-03876-02控制器模块 PDF资料

1.产 品 资 料 介 绍：

产品概述

GIDDINGS & LEWIS 502-03876-02 控制器模块是一款高性能数控系统核心处理单元。它用于协调机床或自动化设备的输入输出信号、伺服驱动器指令以及执行机构动作，实现复杂工艺的高精度运动控制。该模块具备高速处理能力、实时响应性能和强大的扩展性，是多轴数控机床及工业自动化系统的重要控制核心。

技术参数（典型）

• 处理能力：高性能数字处理器，支持多轴运动控制

• 通讯接口：支持工业总线及G&L专用高速接口

• 输入/输出支持：可管理多路数字量与模拟量信号

• 程序存储：内置高速存储器，可存储复杂加工程序和逻辑指令

• 扩展能力：可与伺服驱动器、执行控制板及输入输出模块协同工作

• 实时性：毫秒级指令处理能力，适合高动态和高精度控制需求

• 保护机制：过载、短路、过压及信号异常保护

• 安装方式：模块化插卡设计，方便机柜或机架集成

应用场景

1. 多轴数控机床

• 控制主轴、进给轴及刀库，实现高速切削和自动换刀操作。

2. 自动化生产线

• 协调装配、输送及分拣工位，实现动作同步和流程控制。

3. 工业机器人系统

• 管理多关节机械手及末端工具，实现高精度轨迹控制与多轴联动。

4. 包装与印刷机械

• 控制送料、切割及封装动作，保证高速高精度生产。

5. 纺织与特殊工艺设备

• 驱动卷绕、张力和走布系统，实现高精度生产与工艺控制。

6. 科研与测试平台

• 支持多轴伺服实验台和动态测试设备，实现复杂动作序列精确执行。

英文资料：

Product Overview

The GIDINGS&LEWIS 502-03876-02 controller module is a high-performance CNC system core processing unit. It is used to coordinate the input and output signals, servo drive instructions, and actuator actions of machine tools or automation equipment, achieving high-precision motion control of complex processes. This module has high-speed processing capability, real-time response performance, and strong scalability, and is an important control core for multi axis CNC machine tools and industrial automation systems.

Technical parameters (typical)

Processing capability: High performance digital processor, supporting multi axis motion control

Communication interface: Supports industrial bus and G&L dedicated high-speed interface

Input/output support: can manage multiple digital and analog signals

Program storage: Built in high-speed memory, capable of storing complex machining programs and logical instructions

Scalability: Can work in conjunction with servo drives, execution control boards, and input/output modules

Real time performance: millisecond level instruction processing capability, suitable for high dynamic and high-precision control requirements

Protection mechanism: Overload, short circuit, overvoltage, and signal abnormality protection

Installation method: Modular card insertion design, convenient for cabinet or rack integration

Application scenarios

multi-axis nc machine tool

Control the spindle, feed axis, and tool magazine to achieve high-speed cutting and automatic tool changing operations.

Automatic production line

Coordinate assembly, conveying, and sorting stations to achieve synchronized actions and process control.

Industrial Robot System

Manage multi joint robotic arms and end tools to achieve high-precision trajectory control and multi axis linkage.

Packaging and Printing Machinery

Control feeding, cutting, and packaging actions to ensure high-speed and high-precision production.

Textile and Special Craft Equipment

Drive winding, tension, and feeding systems to achieve high-precision production and process control.

Research and Testing Platform

Support multi axis servo test benches and dynamic testing equipment to achieve precise execution of complex action sequences.
