GIDDINGS & LEWIS M.1302.8416 伺服驱动器 PDF资料

1.产 品 资 料 介 绍：

产品概述

GIDDINGS & LEWIS M.1302.8416 伺服驱动器是一款高性能单轴伺服驱动模块，专为数控机床和工业自动化系统设计。该驱动器可精确控制交流或无刷直流伺服电机，实现位置、速度和扭矩的闭环控制。M.1302.8416 驱动器在高动态响应、稳定性和可靠性方面表现优异，是G&L伺服控制系统中的关键执行组件。

技术参数（典型）

• 控制轴数：单轴伺服驱动

• 输入电源：三相 AC 工业电源（典型 220V/380V/460V）

• 输出能力：中高功率伺服电机驱动，稳定电流输出

• 控制模式：位置控制、速度控制、扭矩控制

• 反馈接口：支持增量编码器、高分辨率解析器及闭环控制

• 通讯接口：与G&L控制器或上位系统高速数据交换

• 保护功能：过压、欠压、过流、过热、短路及编码器故障保护

• 冷却方式：风冷或自然冷却

• 响应特性：快速动态响应，满足频繁启停及高速加减速要求

应用场景

1. 数控机床

• 控制主轴或进给轴，实现高速切削、精密加工及自动换刀操作。

2. 多轴自动化装配系统

• 驱动机器人关节或多轴工位，保证复杂动作的精确同步。

3. 高速包装与印刷设备

• 控制送料、切割、封装或印刷头，实现高节拍、高精度动作。

4. 纺织机械

• 驱动卷绕机、走布装置及张力控制系统，提高生产工艺稳定性。

5. 科研与测试平台

• 支持多轴伺服实验台和动态测试设备，实现高精度实验动作控制。

6. 特殊加工设备

• 驱动切削、钻孔、喷涂等特种工艺设备，实现稳定、高精度操作。

英文资料：

Product Overview

GIDINGS&LEWIS M.1302.8416 servo drive is a high-performance single axis servo drive module designed specifically for CNC machine tools and industrial automation systems. This driver can accurately control AC or brushless DC servo motors, achieving closed-loop control of position, speed, and torque. M. The 1302.8416 driver exhibits excellent performance in high dynamic response, stability, and reliability, and is a key execution component in G&L servo control systems.

Technical parameters (typical)

Number of control axes: single axis servo drive

Input power supply: three-phase AC industrial power supply (typical 220V/380V/460V)

Output capability: Driven by medium to high power servo motors, stable current output

Control modes: position control, speed control, torque control

Feedback interface: Supports incremental encoders, high-resolution parsers, and closed-loop control

Communication interface: high-speed data exchange with G&L controller or upper system

Protection function: overvoltage, undervoltage, overcurrent, overheating, short circuit, and encoder fault protection

Cooling method: air cooling or natural cooling

Response characteristics: Fast dynamic response, meeting the requirements of frequent start stop and high-speed acceleration and deceleration

Application scenarios

CNC machine tool

Control the spindle or feed axis to achieve high-speed cutting, precision machining, and automatic tool changing operations.

Multi axis automated assembly system

Drive robot joints or multi axis workstations to ensure precise synchronization of complex movements.

High speed packaging and printing equipment

Control feeding, cutting, packaging, or printing heads to achieve high tempo and high-precision movements.

textile machinery

Drive the winding machine, feeding device, and tension control system to improve the stability of the production process.

Research and Testing Platform

Support multi axis servo test benches and dynamic testing equipment to achieve high-precision experimental motion control.

Special processing equipment

Drive special process equipment such as cutting, drilling, and spraying to achieve stable and high-precision operation.
