GIDDINGS & LEWIS 501-04301-02交流输出模块 PDF资料

1.产 品 资 料 介 绍：

产品概述

GIDDINGS & LEWIS 501-04301-02 交流输出模块是一款用于工业自动化和数控系统的核心执行模块。它主要负责将控制器发出的指令转换为交流电信号，驱动伺服电机、交流继电器、接触器或其他交流执行装置，从而实现精确的动作控制。该模块通常作为数控机床和自动化生产线的关键接口部件，保证执行动作的准确性与可靠性。

技术参数（典型）

• 输出类型：交流电压/电流输出

• 输出通道：多通道设计，可驱动多个执行装置

• 电压等级：常用工业交流电压（如120V/230V/380V AC）

• 控制模式：开关控制、脉冲控制或可调幅度输出

• 接口兼容性：可与G&L控制器及其它标准工业控制器配合使用

• 响应速度：高响应能力，满足快速动作控制需求

• 保护功能：短路、过载、过压保护，保证模块及设备安全

• 安装方式：模块化插板设计，便于扩展和替换

• 状态指示：LED显示输出状态及故障诊断信息

应用场景

1. 数控机床

• 驱动主轴、进给轴或其他交流负载，实现高速切削和精准定位。

2. 自动化生产线

• 控制交流马达、泵、风机等设备，实现动作同步与流程控制。

3. 工业机器人

• 为关节或末端执行器提供交流动力，实现精确动作执行。

4. 包装与印刷机械

• 控制切割、送料和封装设备的交流电驱动，保证高节拍和稳定性。

5. 纺织机械

• 驱动卷绕机、张力控制装置和走布系统，提高工艺稳定性。

6. 实验与测试平台

• 用于交流负载的动作控制和动态测试，实现多通道精确执行。

英文资料：

Product Overview

GIDINGS&LEWIS 501-04301-02 AC output module is a core execution module used in industrial automation and numerical control systems. It is mainly responsible for converting the instructions issued by the controller into AC signals, driving servo motors, AC relays, contactors or other AC actuators, thereby achieving precise action control. This module is usually used as a key interface component for CNC machine tools and automated production lines, ensuring the accuracy and reliability of executing actions.

Technical parameters (typical)

Output type: AC voltage/current output

Output channel: Multi channel design, capable of driving multiple execution devices

Voltage level: commonly used industrial AC voltage (such as 120V/230V/380V AC)

Control mode: switch control, pulse control, or adjustable amplitude output

Interface compatibility: Can be used in conjunction with G&L controllers and other standard industrial controllers

Response speed: High responsiveness, meeting the requirements of fast action control

Protection function: Short circuit, overload, overvoltage protection, ensuring the safety of modules and equipment

Installation method: Modular plug-in board design, easy to expand and replace

Status indication: LED displays output status and fault diagnosis information

Application scenarios

CNC machine tool

Drive the spindle, feed shaft, or other AC loads to achieve high-speed cutting and precise positioning.

Automatic production line

Control communication motors, pumps, fans, and other equipment to achieve action synchronization and process control.

industrial robot

Provide AC power to joints or end effectors to achieve precise motion execution.

Packaging and Printing Machinery

Control the AC drive of cutting, feeding, and packaging equipment to ensure high cycle time and stability.

textile machinery

Drive the winding machine, tension control device, and feeding system to improve process stability.

Experimental and testing platform

Used for action control and dynamic testing of communication loads, achieving multi-channel precise execution.
