GIDDINGS & LEWIS 502-04137-00逻辑控制器 PDF资料

1.产 品 资 料 介 绍：

产品概述

GIDDINGS & LEWIS 502-04137-00 逻辑控制器是一款应用于自动化系统和数控设备的核心控制单元。它主要用于逻辑运算、顺序控制以及与外围设备的信号交互，是实现复杂工艺流程自动化的关键模块。该控制器可单独使用，也可作为完整运动控制系统中的核心部件，具有可靠性高、运算速度快、接口灵活的特点。

技术参数（典型）

• 处理能力：内置高性能处理器，支持实时逻辑运算

• I/O接口：提供多路数字量输入输出端口，支持扩展模块连接

• 通讯能力：兼容多种工业通讯协议（如串行总线、现场总线）

• 存储功能：具备程序和数据存储空间，可实现多工艺流程控制

• 电源要求：工业标准直流/交流供电（典型 24VDC 或 120/240VAC）

• 保护机制：支持过压、过流及I/O过载保护

• 安装方式：标准机架式或模块化插板式设计，方便系统集成

应用场景

1. 数控机床

• 控制机床的逻辑流程、动作顺序及辅助功能，实现自动化加工。

2. 自动化生产线

• 协调输送、装配、检测等设备的运行逻辑，保证节拍一致。

3. 包装设备

• 用于控制送料、封装、切割等工序的逻辑动作。

4. 机器人系统

• 作为运动控制和逻辑判断的核心单元，实现多轴协同作业。

5. 测试与检测设备

• 执行测试流程逻辑控制，配合传感器实现自动化检测。

6. 物料搬运系统

• 控制输送机、堆垛机、升降机等设备的运行顺序和安全逻辑。

英文资料：

Product Overview

The GIDINGS&LEWIS 502-04137-00 logic controller is a core control unit used in automation systems and CNC equipment. It is mainly used for logical operations, sequential control, and signal interaction with peripheral devices, and is a key module for achieving automation of complex process flows. This controller can be used independently or as a core component in a complete motion control system, with the characteristics of high reliability, fast computation speed, and flexible interface.

Technical parameters (typical)

Processing capability: Built in high-performance processor, supporting real-time logical operations

I/O interface: Provides multiple digital input and output ports, supports expansion module connections

Communication capability: Compatible with multiple industrial communication protocols (such as serial bus, fieldbus)

Storage function: With program and data storage space, it can achieve multi process control

Power requirements: Industrial standard DC/AC power supply (typical 24VDC or 120/240VAC)

Protection mechanism: Supports overvoltage, overcurrent, and I/O overload protection

Installation method: Standard rack mounted or modular plug-in design, convenient for system integration

Application scenarios

CNC machine tool

Control the logical flow, action sequence, and auxiliary functions of the machine tool to achieve automated machining.

Automatic production line

Coordinate the operation logic of conveying, assembly, testing and other equipment to ensure consistent rhythm.

packaging equipment

Used to control the logical actions of feeding, packaging, cutting and other processes.

robot system

As the core unit of motion control and logical judgment, it realizes multi axis collaborative operation.

Testing and Inspection Equipment

Execute testing process logic control and cooperate with sensors to achieve automated detection.

Material Handling System

Control the operation sequence and safety logic of equipment such as conveyors, stackers, and elevators.
