GIDDINGS & LEWIS 502-03840-03伺服编码器 PDF资料

1.产 品 资 料 介 绍：

产品概述

GIDDINGS & LEWIS 502-03840-03 伺服编码器是一种高精度位置反馈装置，主要用于伺服驱动和运动控制系统中。它通过将机械位移转换为电信号，实时反馈给伺服控制器，从而实现电机的速度、位置和方向的精确控制。该编码器是G&L运动控制系统的重要组成部分。

应用领域

1. 数控机床（CNC）

• 用于车床、铣床、磨床和加工中心的主轴和伺服电机位置反馈，保证加工精度和重复性。

2. 工业机器人

• 在关节伺服电机中应用，实现多轴协同运动，确保机器人定位精度和轨迹控制稳定性。

3. 自动化生产线

• 应用于输送系统、装配设备、分拣机构中，提供实时位置检测，保证节拍控制和动作同步。

4. 包装机械

• 用于卷绕、切割、送料环节的精确运动控制，实现高速、高一致性的包装过程。

5. 印刷与纺织设备

• 在卷材走纸、走布系统中使用，实现张力控制和精准同步，避免偏移和误差。

6. 电梯与起重设备

• 作为电机的位移与速度检测元件，确保运行平稳和安全定位。

7. 能源与测试设备

• 应用于风机试验台、伺服试验平台等场合，用于扭矩与转速检测和控制反馈。

应用价值

• 提高运动控制系统的精度与稳定性

• 实现复杂工序的自动化和同步化

• 提升设备的运行效率，降低误差率

• 在恶劣工况下依旧保持可靠的反馈信号

英文资料：

Product Overview

GIDINGS&LEWIS 502-03840-03 servo encoder is a high-precision position feedback device mainly used in servo drive and motion control systems. It converts mechanical displacement into electrical signals and provides real-time feedback to the servo controller, thereby achieving precise control of the motor's speed, position, and direction. This encoder is an important component of the G&L motion control system.

Application field

Numerical Control Machine Tool (CNC)

Used for spindle and servo motor position feedback in lathes, milling machines, grinders, and machining centers to ensure machining accuracy and repeatability.

industrial robot

Applied in joint servo motors to achieve multi axis coordinated motion, ensuring robot positioning accuracy and trajectory control stability.

Automatic production line

Applied in conveying systems, assembly equipment, and sorting mechanisms, providing real-time position detection to ensure beat control and action synchronization.

packaging machinery

Used for precise motion control in winding, cutting, and feeding processes, achieving high-speed and highly consistent packaging processes.

Printing and Textile Equipment

Used in roll paper and fabric feeding systems to achieve tension control and precise synchronization, avoiding offset and errors.

Elevators and lifting equipment

As a displacement and speed detection component of the motor, it ensures smooth operation and safe positioning.

Energy and testing equipment

Applied to wind turbine test benches, servo test platforms, and other occasions, used for torque and speed detection and control feedback.

applied value

Improve the accuracy and stability of motion control systems

Realize automation and synchronization of complex processes

Improve the operational efficiency of equipment and reduce error rates

Maintain reliable feedback signals even under harsh working conditions
