GIDDINGS & LEWIS 502-02813-00输入输出主板 PDF资料

1.产 品 资 料 介 绍：

产品概述

GIDDINGS & LEWIS 502-02813-00 输入输出主板是一款工业级控制核心模块，专门用于数控机床和自动化生产系统的数据采集与信号分发。它可将来自传感器、开关及其他外围设备的输入信号进行处理，并将控制指令输出到执行器、伺服驱动器或其他控制单元，实现整个系统的高效协作。该主板在工业自动化环境中发挥核心桥梁作用，确保设备运行稳定可靠。

技术特性

• 多通道输入/输出：支持数字量和模拟量信号输入输出，满足复杂控制需求。

• 高速处理能力：实时响应输入信号，保证输出控制动作的及时性。

• 通信接口：可与 G&L 控制器、伺服模块及上位机进行数据交换，支持标准工业总线协议。

• 状态指示：LED 指示输入输出状态，便于运行监控和故障诊断。

• 工业适应性：抗振动、耐高温、抗电磁干扰，适合车间和工业环境。

• 模块化设计：便于快速安装、维护和功能扩展。

应用场景

1. 数控机床

• 接收限位开关、刀库状态及传感器信号，实现精确动作控制。

2. 自动化生产线

• 控制输送设备、装配单元及分拣装置的动作执行。

3. 工业机器人系统

• 处理机器人传感器数据，并将控制指令发送至伺服驱动器。

4. 包装与印刷机械

• 协调送料、定位、切割及封装设备的动作同步。

5. 实验和测试平台

• 采集传感器数据，并控制实验设备或测试装置的动作执行。

英文资料：

Product Overview

The GIDINGS&LEWIS 502-02813-00 input/output motherboard is an industrial grade control core module specifically designed for data acquisition and signal distribution in CNC machine tools and automated production systems. It can process input signals from sensors, switches, and other peripheral devices, and output control instructions to actuators, servo drives, or other control units to achieve efficient collaboration of the entire system. This motherboard plays a core bridging role in industrial automation environments, ensuring stable and reliable equipment operation.

Technical Characteristics

Multi channel input/output: Supports digital and analog signal input/output to meet complex control requirements.

High speed processing capability: Real time response to input signals to ensure timely output control actions.

Communication interface: capable of exchanging data with G&L controllers, servo modules, and upper computers, supporting standard industrial bus protocols.

Status indication: LED indicates input and output status, facilitating operation monitoring and fault diagnosis.

Industrial adaptability: resistant to vibration, high temperature, electromagnetic interference, suitable for workshops and industrial environments.

Modular design: easy to install, maintain, and expand functionality quickly.

Application scenarios

CNC machine tool

Receive limit switches, tool magazine status, and sensor signals to achieve precise action control.

Automatic production line

Control the execution of actions for conveying equipment, assembly units, and sorting devices.

Industrial Robot System

Process robot sensor data and send control instructions to servo drives.

Packaging and Printing Machinery

Coordinate and synchronize the actions of feeding, positioning, cutting, and packaging equipment.

Experimental and testing platform

Collect sensor data and control the operation of experimental equipment or testing devices.

2.产      品      展      示
