GIDDINGS & LEWIS 503-26606-00可编程式机器控制模块 PDF资料

1.产 品 资 料 介 绍：

产品概述

GIDDINGS & LEWIS 503-26606-00 可编程式机器控制模块是一款工业级控制单元，用于数控机床及自动化机械的逻辑控制、动作顺序管理及设备协调。该模块具有可编程功能，可通过用户编写程序来定义复杂动作逻辑，实现对多轴机械、伺服驱动及外围执行机构的精确控制。它是 GIDDINGS & LEWIS 系列控制系统中的核心组件，旨在提升机械设备的自动化水平和生产效率。

技术参数（典型特征，型号相关）

• 控制功能：支持顺序逻辑控制、多任务并行执行及事件驱动控制。

• 可编程能力：兼容梯形图、顺序功能图及文本编程，便于定制动作流程。

• 输入/输出接口：内置多通道数字量输入/输出，可扩展外部 I/O 模块。

• 通信接口：支持与上位控制器、伺服驱动器及 I/O 模块的数据通信。

• 执行精度：快速响应控制信号，支持高精度动作控制。

• 工业环境适应性：设计符合工业标准，抗干扰、耐高温及抗振动能力强。

• 安全保护：具备过流、过压、短路保护及自诊断功能。

应用场景

1. 数控机床控制

• 控制主轴、刀库、冷却泵及多轴联动，实现精密加工。

2. 自动化生产线

• 管理输送、装配、分拣及检测设备的动作顺序和同步。

3. 工业机器人系统

• 驱动机器人关节和末端执行器，实现复杂任务动作协调。

4. 包装与印刷设备

• 实现快速启停、定位控制和多段工艺流程管理。

5. 过程控制与实验设备

• 控制泵、阀门、传感器和执行器的动作，实现自动化流程。

英文资料：

Product Overview

GIDINGS&LEWIS 503-26606-00 Programmable Machine Control Module is an industrial grade control unit used for logic control, action sequence management, and equipment coordination of CNC machine tools and automated machinery. This module has programmable functionality and can define complex action logic through user written programs, achieving precise control of multi axis machinery, servo drives, and peripheral actuators. It is the core component of the GIDINGS&LEWIS series control system, aimed at improving the automation level and production efficiency of mechanical equipment.

Technical parameters (typical features, model related)

Control function: Supports sequential logic control, multitasking parallel execution, and event driven control.

Programmable ability: compatible with ladder diagrams, sequential function diagrams, and text programming, making it easy to customize action processes.

Input/output interface: Built in multi-channel digital input/output, expandable external I/O modules.

Communication interface: Supports data communication with upper level controllers, servo drivers, and I/O modules.

Execution accuracy: Quickly respond to control signals and support high-precision action control.

Industrial environment adaptability: Designed to meet industrial standards, with strong anti-interference, high temperature resistance, and vibration resistance capabilities.

Security protection: equipped with overcurrent, overvoltage, short-circuit protection and self diagnostic functions.

Application scenarios

Numerical Control Machine Tool Control

Control the spindle, tool magazine, cooling pump, and multi axis linkage to achieve precision machining.

Automatic production line

Manage the sequence and synchronization of actions for conveying, assembling, sorting, and testing equipment.

Industrial Robot System

Drive robot joints and end effectors to achieve coordination of complex task actions.

Packaging and Printing Equipment

Realize fast start stop, positioning control, and multi-stage process management.

Process Control and Experimental Equipment

Control the actions of pumps, valves, sensors, and actuators to achieve automated processes.

2.产      品      展      示
