GIDDINGS & LEWIS M.1017.3888以太网模块 PDF资料

1.产 品 资 料 介 绍：

产品概述

GIDDINGS & LEWIS M.1017.3888 以太网模块是一款工业级通信扩展模块，专为数控机床、自动化生产线及工业控制系统设计。它提供高速、可靠的以太网接口，用于实现控制器、I/O 模块和上位管理系统之间的数据交换。该模块支持实时数据传输和远程监控功能，是工业控制系统网络化和智能化的重要组成部分。

技术参数（典型特征，型号相关）

• 接口类型：标准工业以太网接口（RJ45），支持 10/100 Mbps 传输速率。

• 协议支持：兼容 TCP/IP、UDP 等标准网络协议，部分型号支持 Modbus TCP 或 Profinet。

• 数据传输：低延迟、高可靠性数据传输，支持实时控制与状态反馈。

• 扩展能力：可与 GIDDINGS & LEWIS 系列控制器及 I/O 模块无缝集成。

• 电气特性：具备隔离保护、浪涌抑制和抗干扰设计。

• 状态指示：LED 指示网络状态、数据传输状态及模块运行状态。

• 安装方式：模块化设计，便于在控制柜或机床系统中快速安装和更换。

应用场景

1. 数控机床

• 实现机床控制器与上位计算机或其他控制模块的数据交换和状态监控。

2. 自动化生产线

• 支持各工位控制器的网络化通信，保障生产过程数据实时同步。

3. 工业机器人系统

• 提供机器人控制器与传感器、I/O 模块及调度系统之间的高速通信。

4. 工厂信息化/MES 对接

• 将生产数据传输到上位管理系统，实现生产监控和工艺优化。

5. 过程控制与远程监控

• 用于传输实时数据，实现远程诊断和故障报警。

英文资料：

Product Overview

GIDINGS&LEWIS M.1017.3888 Ethernet module is an industrial grade communication expansion module designed specifically for CNC machine tools, automated production lines, and industrial control systems. It provides a high-speed and reliable Ethernet interface for data exchange between controllers, I/O modules, and upper management systems. This module supports real-time data transmission and remote monitoring functions, and is an important component of industrial control system networking and intelligence.

Technical parameters (typical features, model related)

Interface type: Standard industrial Ethernet interface (RJ45), supporting 10/100 Mbps transmission rate.

Protocol support: Compatible with standard network protocols such as TCP/IP and UDP, and some models support Modbus TCP or Profinet.

Data transmission: Low latency, high reliability data transmission, supporting real-time control and status feedback.

Scalability: Seamless integration with GIDDINGS&LEWIS series controllers and I/O modules.

Electrical characteristics: Equipped with isolation protection, surge suppression, and anti-interference design.

Status indication: LED indicates network status, data transmission status, and module operation status.

Installation method: Modular design, easy to quickly install and replace in control cabinets or machine tool systems.

Application scenarios

CNC machine tool

Realize data exchange and status monitoring between the machine tool controller and the upper computer or other control modules.

Automatic production line

Support networked communication of controllers at each workstation to ensure real-time synchronization of production process data.

Industrial Robot System

Provide high-speed communication between robot controllers, sensors, I/O modules, and scheduling systems.

Factory informatization/MES docking

Transfer production data to the upper management system to achieve production monitoring and process optimization.

Process control and remote monitoring

Used for transmitting real-time data, achieving remote diagnosis and fault alarm.

2.产      品      展      示
