GIDDINGS & LEWIS 401-56453-00伺服驱动器 PDF资料
1.产 品 资 料 介 绍：
产品概述
GIDDINGS & LEWIS 401-56453-00 伺服驱动器是一款工业级交流伺服驱动装置，主要配合无刷交流伺服电机使用，提供高精度的位置、速度和扭矩控制。该驱动器适用于数控机床、工业自动化生产线及机器人等对动态响应和控制精度要求较高的场合，具备稳定性好、扩展性强和自诊断功能完善等特点。
技术参数（典型特征，型号相关）
电源输入：支持三相工业交流输入，具备过压、欠压及相序保护。
电机适配：专为 GIDDINGS & LEWIS 无刷交流伺服电机优化，支持多规格功率段。
控制模式：位置控制 / 速度控制 / 扭矩控制，多模式灵活切换。
反馈接口：支持编码器反馈，保证闭环高精度控制。
保护功能：过流、过载、过温、短路保护，提高系统可靠性。
通讯能力：兼容标准工业总线和 GIDDINGS & LEWIS 自有控制系统，支持集中监控与远程调试。
结构特性：模块化设计，便于安装、扩展和维护。
应用场景
数控机床
主轴及进给伺服控制，保证高精度切削与平稳加工。
自动化生产线
驱动输送、装配、分拣等执行机构，提升生产效率。
工业机器人
控制关节运动和末端执行器动作，实现高速、高精度作业。
包装设备
实现快速启停和精准定位，适合高速包装和分切工艺。
印刷与纺织机械
保证多电机同步，支持高速稳定运行。
英文资料：
Product Overview
GIDINGS&LEWIS 401-56453-00 servo drive is an industrial grade AC servo drive device, mainly used in conjunction with brushless AC servo motors, providing high-precision position, speed, and torque control. This driver is suitable for applications such as CNC machine tools, industrial automation production lines, and robots that require high dynamic response and control accuracy. It has the characteristics of good stability, strong scalability, and complete self diagnostic functions.
Technical parameters (typical features, model related)
Power input: Supports three-phase industrial AC input, with overvoltage, undervoltage, and phase sequence protection.
Motor adaptation: specifically optimized for GIDDINGS&LEWIS brushless AC servo motors, supporting multiple power ranges.
Control modes: position control/speed control/torque control, flexible switching between multiple modes.
Feedback interface: Supports encoder feedback to ensure high-precision closed-loop control.
Protection function: over-current, overload, over temperature, short circuit protection to improve system reliability.
Communication capability: Compatible with standard industrial buses and GIDINGS&LEWIS proprietary control systems, supporting centralized monitoring and remote debugging.
Structural characteristics: Modular design, easy to install, expand, and maintain.
Application scenarios
CNC machine tool
Spindle and feed servo control ensure high-precision cutting and smooth machining.
Automatic production line
Drive conveying, assembly, sorting and other execution mechanisms to improve production efficiency.
industrial robot
Control joint movements and end effector actions to achieve high-speed and high-precision operations.
packaging equipment
Realize fast start stop and precise positioning, suitable for high-speed packaging and cutting processes.
Printing and Textile Machinery
Ensure multi motor synchronization and support high-speed and stable operation.
2.产 品 展 示
