GIDDINGS & LEWIS  NSM5630 伺服电机 PDF资料

1.产 品 资 料 介 绍：

产品概述

NSM5630 是 GIDDINGS & LEWIS 推出的高扭矩、低惯量伺服电机，专为高精度加工和快速响应的工业应用设计。它不仅适合数控机床，也适合多轴自动化系统和机器人关节驱动，能够在高动态环境下保持稳定运动，并减少机械振动对加工精度的影响。

技术特点

• 低惯量设计：实现快速启动和制动，适合高速变向运动。

• 高扭矩输出：在紧凑尺寸下提供强劲动力，适应高负载工况。

• 内置高分辨率编码器：支持微米级定位和精细运动控制。

• 过热保护：在连续运行高负载下自动调节功率，保证电机寿命。

• 抗振动与抗干扰：优化轴承与电机结构，适合恶劣工业环境。

应用场景

1. 高速数控加工

• 用于主轴或刀具轴，实现快速切换和精确加工曲面。

2. 多轴工业机器人

• 驱动机器人关节，完成精密抓取、装配或焊接任务。

3. 精密装配线

• 提供快速、稳定的动作，保证多工序同步和高重复定位精度。

4. 测试与测量设备

• 在实验台、测量平台中提供稳定扭矩和微米级定位能力。

产品优势

• 高动态性能：低惯量和高扭矩结合，使设备响应更快。

• 加工精度高：高分辨率编码器配合闭环控制，实现微米级定位。

• 适应恶劣环境：抗振动、防尘、防电磁干扰设计保证长期稳定运行。

• 节能可靠：优化电机效率，减少能量损耗和热量生成。

• 安装灵活：紧凑体积易于集成，多种安装方式适应不同设备布局。

英文资料：

Product Overview

NSM5630 is a high torque, low inertia servo motor developed by GIDINGS&LEWIS, specifically designed for industrial applications with high-precision machining and fast response. It is not only suitable for CNC machine tools, but also for multi axis automation systems and robot joint drives, which can maintain stable motion in high dynamic environments and reduce the impact of mechanical vibration on machining accuracy.

Technical Features

Low inertia design: achieves fast starting and braking, suitable for high-speed directional motion.

High torque output: Provides strong power in a compact size, suitable for high load conditions.

Built in high-resolution encoder: supports micrometer level positioning and fine motion control.

Overheating protection: Automatically adjust power under continuous high load operation to ensure motor lifespan.

Anti vibration and anti-interference: Optimized bearing and motor structure, suitable for harsh industrial environments.

Application scenarios

High speed CNC machining

Used for spindle or tool axis, achieving fast switching and precise machining of surfaces.

Multi axis industrial robot

Drive robot joints to complete precision grasping, assembly, or welding tasks.

Precision assembly line

Provide fast and stable actions to ensure multi process synchronization and high repeatability positioning accuracy.

Testing and measuring equipment

Provide stable torque and micrometer level positioning capability in experimental and measurement platforms.

Product advantages

High dynamic performance: The combination of low inertia and high torque makes the equipment respond faster.

High processing accuracy: High resolution encoder combined with closed-loop control achieves micrometer level positioning.

Adapt to harsh environments: anti vibration, dust-proof, and anti electromagnetic interference design ensures long-term stable operation.

Energy saving and reliable: Optimize motor efficiency, reduce energy loss and heat generation.

Flexible installation: Compact size and easy integration, multiple installation methods to adapt to different device layouts.
