GIDDINGS & LEWIS  FSM460伺服电机 PDF资料

1.产 品 资 料 介 绍：

产品概述

GIDDINGS & LEWIS FSM460 伺服电机是一款高性能交流伺服驱动装置，专为数控机床和工业自动化设备设计。该电机可实现精确位置控制和高速响应，支持复杂工艺动作的执行。其紧凑设计结合高扭矩输出，使其在空间有限的工业设备中也能提供可靠动力。

技术参数

• 产品类型：交流伺服电机

• 型号：FSM460

• 额定功率：中高功率等级，满足数控加工及自动化设备需求

• 额定电压：AC 220–480V（具体视设备配置）

• 额定转速：通常可达数千转每分钟，支持高速精密加工

• 控制方式：闭环伺服控制，支持位置、速度及扭矩调节

• 反馈装置：高精度编码器，实现精确位置和速度反馈

• 防护等级：IP54 或更高，具备防尘、防水能力

• 环境适应性：耐高温、高湿及机械振动，抗电磁干扰

应用场景

1. 数控机床

• 驱动主轴、工作台或刀具轴，实现高精度多轴加工。

• 支持轮廓加工、曲面加工及复杂零件加工。

2. 工业自动化系统

• 用于机械臂、传输系统和自动装配设备的高精度动作控制。

• 实现平稳运动和精确定位，保证生产工艺质量。

3. 精密加工设备

• 驱动铣削、钻孔、磨削及其他高精度加工工序。

• 提供稳定转矩和响应速度，优化加工效率和质量。

英文资料：

Product Overview

GIDINGS&LEWIS FSM460 servo motor is a high-performance AC servo drive device designed specifically for CNC machine tools and industrial automation equipment. This motor can achieve precise position control and high-speed response, supporting the execution of complex process actions. Its compact design combined with high torque output enables it to provide reliable power even in industrial equipment with limited space.

Technical Specifications

Product type: AC servo motor

Model: FSM460

Rated power: medium to high power level, meeting the requirements of CNC machining and automation equipment

Rated voltage: AC 220-480V (depending on equipment configuration)

Rated speed: usually up to several thousand revolutions per minute, supporting high-speed precision machining

Control mode: closed-loop servo control, supporting position, speed, and torque adjustment

Feedback device: high-precision encoder, achieving precise position and velocity feedback

Protection level: IP54 or higher, with dustproof and waterproof capabilities

Environmental adaptability: resistant to high temperature, high humidity, and mechanical vibration, resistant to electromagnetic interference

Application scenarios

CNC machine tool

Drive the spindle, worktable or tool shaft to achieve high-precision multi axis machining.

Support contour machining, surface machining, and complex part machining.

Industrial automation system

High precision motion control for robotic arms, transmission systems, and automatic assembly equipment.

Realize smooth movement and precise positioning to ensure production process quality.

Precision machining equipment

Drive milling, drilling, grinding, and other high-precision machining processes.

Provide stable torque and response speed, optimize machining efficiency and quality.

2.产      品      展      示
