TOYOTA 24270-12230-71接触器组件 PDF资料

1.产 品 资 料 介 绍：

TOYOTA 24270-12230-71 接触器组件

产品概述

TOYOTA 24270-12230-71 接触器组件是丰田电动叉车电气系统中的关键开关元件，用于控制主电路的通断。它通过接收控制信号切换电源流向，实现电动机、液压泵及其他电气设备的启停管理，保证叉车运行的安全性与可靠性。

产品特点

1. 高承载能力

• 能够承受电动叉车主电路中的高电流负载，保证设备可靠启停。

2. 快速响应

• 对控制信号反应迅速，实现电机及液压系统的即时切换。

3. 耐用性强

• 工业级材料和设计，适应长期振动、冲击及高温环境，使用寿命长。

4. 安全保护

• 内置机械与电气隔离，降低短路或过载风险，提高整车安全性。

5. 维护便捷

• 模块化设计，便于快速检测、更换和维护，减少停机时间。

6. 兼容性好

• 与丰田电动叉车主要系列及相关控制系统匹配，保证电气接口和控制信号稳定可靠。

产品应用领域

1. 主电路控制

• 控制行驶电机、电池电源及液压泵的通断，实现叉车核心功能操作。

2. 驱动系统保护

• 在过载、短路或异常情况下切断电源，防止设备损坏。

3. 液压系统管理

• 与液压泵配合控制货叉升降、倾斜及侧移动作。

4. 辅助设备供电控制

• 可控制照明、报警蜂鸣器及其他辅助电气设备的开关。

5. 工业车辆及自动化设备应用

• 除叉车外，可应用于其他需要高电流控制的搬运或工业自动化设备。

英文资料：

TOYOTA 24270-12230-71 contactor assembly

Product Overview

TOYOTA 24270-12230-71 contactor assembly is a key switch component in the electrical system of Toyota electric forklifts, used to control the on/off of the main circuit. It switches the power flow direction by receiving control signals to achieve start stop management of electric motors, hydraulic pumps, and other electrical equipment, ensuring the safety and reliability of forklift operation.

Product Features

High load-bearing capacity

Capable of withstanding high current loads in the main circuit of electric forklifts, ensuring reliable start stop of equipment.

quick response

React quickly to control signals and achieve instant switching between motors and hydraulic systems.

High durability

Industrial grade materials and design, suitable for long-term vibration, impact, and high temperature environments, with a long service life.

safety protection

Built in mechanical and electrical isolation reduces the risk of short circuit or overload and improves overall vehicle safety.

Convenient maintenance

Modular design facilitates quick detection, replacement, and maintenance, reducing downtime.

Good compatibility

Match with the main series and related control systems of Toyota electric forklifts to ensure stable and reliable electrical interfaces and control signals.

Product application areas

main circuit control

Control the on/off of the driving motor, battery power supply, and hydraulic pump to achieve the core function operation of the forklift.

Drive system protection

Cut off the power supply in case of overload, short circuit, or abnormal conditions to prevent equipment damage.

Hydraulic system management

Cooperate with the hydraulic pump to control the lifting, tilting, and lateral movement of the fork.

Auxiliary equipment power supply control

Switches that can control lighting, alarm buzzers, and other auxiliary electrical equipment.

Application of industrial vehicles and automation equipment

In addition to forklifts, it can be applied to other handling or industrial automation equipment that requires high current control.

2.产      品      展      示
