TOYOTA Fi-DST-1CN-212接口模块 PDF资料

1.产 品 资 料 介 绍：

TOYOTA Fi-DST-1CN-212 接口模块

产品概述

TOYOTA Fi-DST-1CN-212 是丰田电动叉车及工业自动化设备使用的接口模块，主要用于连接控制器与外部信号设备，实现数据传输和信号通信。该模块是系统信号链路中的关键组件，保证主控制器能够准确接收传感器和操作面板的输入，同时将控制指令输出至执行单元。

产品特点

1. 高兼容性

• 可与丰田多款叉车控制器及相关接口设备配合使用，确保系统通信可靠。

2. 稳定信号传输

• 内部电路设计用于消除干扰与信号衰减，保证数据与控制信号的稳定传递。

3. 多功能接口

• 支持数字量、模拟量及脉冲信号输入输出，可连接多种传感器与执行器。

4. 工业级耐用性

• 模块采用耐振动、耐温和防尘设计，适合叉车及工业环境中的长期使用。

5. 安装与维护便捷

• 模块化设计，便于快速安装、拆卸与更换，降低维护成本。

产品应用领域

1. 叉车控制系统

• 用于接收驾驶员操作信号和传感器数据，输出至电机、液压阀及其他执行单元。

2. 液压及驱动管理

• 协助主控制器实现对液压泵、电机驱动及辅助设备的协调控制。

3. 安全与报警系统

• 用于连接安全开关、警报装置和限位传感器，实现整车安全防护。

4. 工业自动化设备接口

• 可扩展应用于自动化搬运车、堆高机等设备的控制与数据采集模块。

英文资料：

TOYOTA Fi-DST-1CN-212 Interface Module

Product Overview

TOYOTA Fi-DST-1CN-212 is an interface module used in Toyota electric forklifts and industrial automation equipment, mainly used to connect controllers with external signal devices, achieve data transmission and signal communication. This module is a key component in the system signal link, ensuring that the main controller can accurately receive inputs from sensors and operation panels, while outputting control instructions to the execution unit.

Product Features

High compatibility

Can be used in conjunction with multiple Toyota forklift controllers and related interface devices to ensure reliable system communication.

Stable signal transmission

The internal circuit design is used to eliminate interference and signal attenuation, ensuring stable transmission of data and control signals.

Multi functional interface

Supports digital, analog, and pulse signal input and output, and can connect multiple sensors and actuators.

Industrial grade durability

The module adopts a vibration resistant, temperature resistant, and dust-proof design, suitable for long-term use in forklifts and industrial environments.

Easy installation and maintenance

Modular design facilitates quick installation, disassembly, and replacement, reducing maintenance costs.

Product application areas

Forklift control system

Used to receive driver operation signals and sensor data, and output them to motors, hydraulic valves, and other execution units.

Hydraulic and Drive Management

Assist the main controller in achieving coordinated control of hydraulic pumps, motor drives, and auxiliary equipment.

Security and alarm system

Used to connect safety switches, alarm devices, and limit sensors to achieve vehicle safety protection.

Industrial automation equipment interface

Can be extended to control and data acquisition modules for automated handling vehicles, stackers, and other equipment.

2.产      品      展      示
