TOYOTA  24230-12242-71直流电源分配板 PDF资料

1.产 品 资 料 介 绍：

TOYOTA 24230-12242-71 直流电源分配板

产品概述

TOYOTA 24230-12242-71 是丰田叉车专用的直流电源分配板（DC-SD Board）。它安装在接触器面板内部，位于斩波器单元旁，用于对电动叉车电源进行分配与稳压。该模块是电控系统中重要的电源管理部件，保障叉车控制系统在不同工况下稳定运行。

技术参数（典型特征）

• 类型：直流电源分配板（DC-SD 模块）

• 功能：分配直流电源，稳压，保障控制器及执行部件电力供应

• 安装位置：接触器面板内，靠近斩波器组件

• 适配机型：主要应用于 Toyota 5FBC 系列电动叉车

• 维护特性：可提供 OEM 原厂件、再制造件或替代件，并支持维修服务

应用场景

1. 叉车驱动系统供电：为驱动电机及控制器提供稳定的直流电源，确保叉车正常行驶。

2. 液压系统供电：通过电源分配，为液压泵及相关电磁阀供电，实现货叉升降与倾斜操作。

3. 控制系统支持：为操作面板、传感器和安全控制单元供电，保证叉车的信号采集与控制逻辑稳定。

4. 电源保护与管理：在电池放电、电流冲击或电压波动时，提供保护与分配，延长整车电气系统寿命。

产品优势

• 稳定可靠：专为丰田电动叉车设计，保证兼容性与高可靠性。

• 电源分配精准：能够对不同子系统合理分配直流电能，提高整车能效。

• 易于维护：模块化设计，支持快速更换或送修，降低维护时间。

• 多种选择：可选择全新件、再制造件或售后替代件，满足不同成本与使用需求。

英文资料：

TOYOTA 24230-12242-71 DC Power Distribution Board

Product Overview

TOYOTA 24230-12242-71 is a DC power distribution board (DC-SD Board) specifically designed for Toyota forklifts. It is installed inside the contactor panel, next to the chopper unit, and is used to distribute and stabilize the power supply of the electric forklift. This module is an important power management component in the electronic control system, ensuring stable operation of the forklift control system under different working conditions.

Technical parameters (typical features)

Type: DC power distribution board (DC-SD module)

Function: Allocate DC power, stabilize voltage, and ensure power supply for controllers and executing components

Installation position: Inside the contactor panel, near the chopper component

Compatible models: mainly used for Toyota 5FBC series electric forklifts

Maintenance feature: Can provide OEM original parts, remanufactured parts or replacement parts, and support repair services

Application scenarios

Forklift drive system power supply: provides stable DC power supply for the drive motor and controller to ensure the normal operation of the forklift.

Hydraulic system power supply: Through power distribution, power is supplied to the hydraulic pump and related solenoid valves to achieve fork lifting and tilting operations.

Control system support: Provide power to the operation panel, sensors, and safety control unit to ensure stable signal acquisition and control logic of the forklift.

Power protection and management: Provide protection and distribution during battery discharge, current surges, or voltage fluctuations to extend the lifespan of the vehicle's electrical system.

Product advantages

Stable and Reliable: Designed specifically for Toyota electric forklifts, ensuring compatibility and high reliability.

Accurate power distribution: able to allocate DC power to different subsystems in a reasonable manner, improving the overall energy efficiency of the vehicle.

Easy to maintain: Modular design, supports quick replacement or repair, reduces maintenance time.

Multiple options: You can choose from brand new parts, remanufactured parts, or after-sales replacement parts to meet different costs and usage needs.

2.产      品      展      示
