TOYOTA TP-1502-5输入输出模块 PDF资料

1.产 品 资 料 介 绍：

产品概述

TOYOTA TP-1502-5 输入输出模块属于丰田（Toyoda/JTEKT）工业控制系统的机架式模块，用于实现设备与可编程逻辑控制器（PLC）之间的信号交互。该模块可以同时处理数字量输入和输出信号，在自动化生产设备中作为数据采集与执行命令的桥梁。

技术参数（推测基于同系列模块）

• 模块类型：数字量输入/输出（I/O）模块

• 安装方式：机架式插槽安装

• 信号类型：支持多通道数字输入与数字输出

• 接口形式：端子排或专用接插件

• 适用系统：TOYODA/Toyota 自动化控制系统

• 工作环境：工业环境（抗干扰、耐温差）

应用场景

1. 机床自动化控制
   安装在CNC加工中心、数控车床、磨床等设备中，用于采集限位开关、传感器等信号，并驱动电磁阀、继电器等执行机构。

2. 生产线与装配线
   应用于汽车零部件生产线、自动化装配生产线，实现多工位的同步控制与信号交换。

3. 物流与搬运设备
   在自动化输送线、分拣机、叉车控制系统中实现动作控制与状态监测。

4. PLC 系统扩展
   扩展 PLC 控制点数，满足大型设备或生产单元对更多输入输出点位的需求。

产品优势

• 兼容性好：与同系列丰田控制系统及PLC配套无缝使用

• 稳定性高：工业级设计，抗电磁干扰能力强

• 维护方便：模块化结构，便于快速更换和系统升级

• 功能集成：输入与输出功能集成在单模块中，节省机架空间

英文资料：

product overview

The TOYOTA TP-1502-5 input/output module is a rack mounted module of Toyota/JTEKT industrial control systems, used to achieve signal interaction between equipment and programmable logic controllers (PLCs). This module can simultaneously process digital input and output signals, serving as a bridge for data acquisition and command execution in automated production equipment.

Technical parameters (presumably based on modules of the same series)

Module Type: Digital Input/Output (I/O) Module

Installation method: Rack mounted slot installation

Signal type: Supports multi-channel digital input and digital output

Interface form: terminal block or dedicated connector

Applicable system: TOYODA/Toyota automation control system

Work environment: Industrial environment (anti-interference, temperature resistance)

Application scenarios

Machine tool automation control

Installed in CNC machining centers, CNC lathes, grinders, and other equipment, it is used to collect signals from limit switches, sensors, and drive actuators such as solenoid valves and relays.

Production line and assembly line

Applied to automotive parts production lines and automated assembly production lines, achieving synchronous control and signal exchange of multiple workstations.

Logistics and handling equipment

Implement motion control and status monitoring in automated conveyor lines, sorting machines, and forklift control systems.

PLC system expansion

Expand the number of PLC control points to meet the needs of large equipment or production units for more input and output points.

Product advantages

Good compatibility: seamlessly compatible with Toyota control systems and PLCs of the same series

High stability: Industrial grade design, strong resistance to electromagnetic interference

Easy to maintain: modular structure for quick replacement and system upgrade

Function integration: Input and output functions are integrated into a single module, saving rack space

2.产      品      展      示
