TOYOTA  TP-1340-3输出通信模块 PDF资料

1.产 品 资 料 介 绍：

产品概述
TOYOTA TP-1340-3 输出通信模块是一款用于丰田自动化生产设备的通信与信号输出接口单元，主要负责将控制系统内部处理好的指令数据转换为外部设备可识别的通信信号或控制信号，并稳定地传输至执行端。该模块在自动化生产线、机器人控制系统及检测设备中广泛使用，可实现多设备间的高速、稳定数据交互。

技术参数（示例，具体以实际设备为准）

• 通信方式：支持工业总线（如RS-232、RS-485、CAN、以太网或丰田定制总线协议）

• 输出通道数：多路独立信号输出（数字量/模拟量依据配置）

• 传输速率：最高可达数Mbps（取决于协议）

• 电源要求：DC 5V / 12V / 24V（依型号）

• 信号隔离：光耦或变压器隔离，提升通信稳定性

• 工作环境：-10℃～+55℃，抗震、防尘设计

• 接口类型：端子排、工业插座或定制连接器

应用场景

1. 生产线数据通信

• 将PLC或主控制系统的输出信号传输至分布式控制单元

• 支持多工位间实时数据交换，保证工序协同

2. 机器人与外部设备联动

• 向工业机器人发送动作控制指令

• 实现机器人与输送、分拣、检测等外围设备的同步运行

3. 检测与质量控制系统

• 向检测设备发送触发信号或工件识别数据

• 将检测结果数据输出到上位机或中央控制系统

4. 远程监控与数据采集

• 将生产现场的实时状态信息输出至监控中心

• 支持远程设备的状态反馈与控制命令传输

英文资料：

product overview

The TOYOTA TP-1340-3 output communication module is a communication and signal output interface unit used in Toyota's automated production equipment. It is mainly responsible for converting the command data processed internally by the control system into recognizable communication or control signals for external devices, and stably transmitting them to the execution end. This module is widely used in automated production lines, robot control systems, and detection equipment, and can achieve high-speed and stable data exchange between multiple devices.

Technical parameters (example, subject to actual equipment)

Communication method: Supports industrial bus (such as RS-232, RS-485, CAN, Ethernet, or Toyota customized bus protocol)

Number of output channels: Multiple independent signal outputs (digital/analog based on configuration)

Transmission rate: up to several Mbps (depending on protocol)

Power requirements: DC 5V/12V/24V (depending on model)

Signal isolation: optocoupler or transformer isolation to enhance communication stability

Working environment: -10 ℃~+55 ℃, designed for earthquake resistance and dust prevention

Interface type: terminal block, industrial socket or customized connector

Application scenarios

Production line data communication

Transmission of output signals from PLC or main control system to distributed control unit

Support real-time data exchange between multiple workstations to ensure process collaboration

Linkage between robots and external devices

Send motion control commands to industrial robots

Realize synchronous operation between robots and peripheral devices such as conveying, sorting, and detection

Testing and Quality Control System

Send trigger signals or workpiece identification data to the detection equipment

Output the detection result data to the upper computer or central control system

Remote monitoring and data collection

Output real-time status information from the production site to the monitoring center

Support remote device status feedback and control command transmission

2.产      品      展      示
