TOYOTA TP-2424-1伺服机箱 PDF资料

1.产 品 资 料 介 绍：

产品概述

TOYOTA TP-2424-1 伺服机箱是专为工业自动化及数控设备设计的伺服驱动系统机箱。该机箱用于安装和保护伺服驱动器及相关控制模块，提供稳定的工作环境，确保伺服系统的高效运行。

主要特点

1. 坚固耐用结构

• 采用高强度金属材料，防尘防震，适应工业现场恶劣环境。

2. 合理布局设计

• 内部空间合理规划，方便安装伺服驱动器及辅助设备，利于散热与维护。

3. 良好散热性能

• 配备散热孔和风扇接口，保证机箱内部温度稳定，延长设备寿命。

4. 标准化接口

• 兼容多种伺服驱动器型号，便于模块化安装和更换。

5. 安全防护措施

• 具备电气隔离和接地设计，保障设备和操作人员安全。

应用领域

• 数控机床

• 作为伺服驱动系统的安装保护平台，支持机床高精度运动控制。

• 自动化生产线

• 安装伺服控制器，驱动机械臂、传送带等自动化设备。

• 设备维护与升级

• 替换或升级现有伺服系统的机箱结构，提升系统稳定性。

• 工业机器人系统

• 保护伺服驱动单元，保障机器人精确动作和安全运行。

英文资料：

product overview

TOYOTA TP-2424-1 servo chassis is a servo drive system chassis designed specifically for industrial automation and CNC equipment. This chassis is used for installing and protecting servo drives and related control modules, providing a stable working environment and ensuring the efficient operation of the servo system.

main features

Durable and sturdy structure

Made of high-strength metal materials, dustproof and shockproof, suitable for harsh industrial environments.

Reasonable layout design

Reasonable internal space planning facilitates the installation of servo drives and auxiliary equipment, facilitating heat dissipation and maintenance.

Good heat dissipation performance

Equipped with heat dissipation holes and fan interfaces to ensure stable temperature inside the chassis and extend device lifespan.

Standardizes interfaces

Compatible with multiple servo drive models, convenient for modular installation and replacement.

Safety protection measures

Equipped with electrical isolation and grounding design to ensure the safety of equipment and operators.

application area

CNC

As an installation protection platform for servo drive systems, it supports high-precision motion control of machine tools.

Automatic production line

Install servo controllers to drive automation equipment such as robotic arms and conveyor belts.

Equipment maintenance and upgrade

Replace or upgrade the chassis structure of the existing servo system to enhance system stability.

Industrial Robot System

Protect the servo drive unit to ensure precise movement and safe operation of the robot.

2.产      品      展      示
