TOYOTA TP-8901-1 电路板 PDF资料
1.产 品 资 料 介 绍:
产品概述
TOYOTA TP-8901-1 电路板(型号 FHOUT-F TP-8901-1)是一种工业自动化设备用的继电器输出控制模块,通常与 TP-8900-0(FHIN-F)输入板配套使用,构成数控机床或自动化控制系统的信号输入输出核心。该板具备多路继电器输出能力,用于驱动外部执行器,实现工业设备的精准控制。
技术参数
型号:TP-8901-1(FHOUT-F)
类型:继电器输出电路板
输出通道:36 路继电器输出
接口配置:15 个 12 针母连接器 + 2 个 CDJR-1 接口
安装方式:模块化机架或插槽安装
适用环境:工业现场,具备抗震动、耐温差能力
配套使用:与 TP-8900-0 输入板配合构成完整 I/O 系统
应用场景
CNC 数控机床
控制机床外部执行装置,如液压夹具、冷却系统、照明、信号指示灯等。
自动化产线控制
作为生产线控制系统的输出模块,驱动电磁阀、继电器组、机械手臂等。
工业控制柜
集成在自动化控制柜中,作为集中输出控制板使用。
设备维护与替换
用于维修或升级老旧 Toyoda 控制系统,替换故障输出板延长设备寿命。
英文资料:
product overview
TOYOTA TP-8901-1 circuit board (model FHOUT-F TP-8901-1) is a relay output control module used in industrial automation equipment. It is usually used in conjunction with TP-8900-0 (FHIN-F) input board to form the signal input and output core of CNC machine tools or automation control systems. This board has the ability to output multiple relays, which are used to drive external actuators and achieve precise control of industrial equipment.
Technical Parameter
Model: TP-8901-1 (FHOUT-F)
Type: Relay output circuit board
Output channel: 36 relay outputs
Interface configuration: 15 12 pin female connectors+2 CDJR-1 interfaces
Installation method: Modular rack or slot installation
Applicable environment: Industrial site, with anti vibration and temperature difference resistance capabilities
Supporting use: Combined with TP-8900-0 input board to form a complete I/O system
Application scenarios
CNC machine tool
Control the external execution devices of the machine tool, such as hydraulic fixtures, cooling systems, lighting, signal indicators, etc.
Automated production line control
As the output module of the production line control system, it drives solenoid valves, relay groups, robotic arms, etc.
Industrial Control Cabinet
Integrated in the automation control cabinet, used as a centralized output control board.
Equipment maintenance and replacement
Used for repairing or upgrading old Toyota control systems, replacing faulty output boards, and extending equipment lifespan.
2.产 品 展 示
