TOYOTA TAP3000-1输入板 PDF资料
1.产 品 资 料 介 绍：
TOYOTA TAP3000-1 输入板 — 产品应用领域
一、产品概述
TOYOTA TAP3000-1 输入板是一种用于工业控制系统的信号输入接口模块，主要应用于丰田（TOYODA/JTEKT）及部分兼容的数控系统中。该模块负责接收外部传感器、开关及操作面板的信号，并将其传输至主控单元进行处理，实现设备的精确控制。
二、技术特点
工业级输入接口，抗干扰能力强
支持多路数字量或开关量信号输入
稳定可靠，适应 CNC 机床高振动、高温环境
模块化机架式安装，便于更换与维护
与 CNC 控制器高度兼容，信号传输延迟低
三、应用领域
数控机床输入模块
用于车床、铣床、磨床等 CNC 设备的信号采集，实现开关、限位、传感器信号的输入。自动化生产线控制系统
作为输入端模块，将传感器、光电开关等检测信号送入中央控制系统，保障生产过程的自动化运行。工业机器人系统
接收机械手臂位置、限位、工件到位等信号，配合控制器完成精确动作。专用设备控制系统
应用于转台、加工中心及特殊用途机械的输入信号采集与传输。
四、产品优势
信号采集稳定，减少误动作
工业级防护，适应恶劣环境
与多种工业控制系统兼容
模块化结构，易于维护和替换
英文资料：
TOYOTA TAP3000-1 Input Board - Product Application Fields
1、 Product Overview
TOYOTA TAP3000-1 input board is a signal input interface module used in industrial control systems, mainly applied in Toyota (TOYODA/JTEKT) and partially compatible CNC systems. This module is responsible for receiving signals from external sensors, switches, and operation panels, and transmitting them to the main control unit for processing, achieving precise control of the equipment.
2、 Technical features
Industrial grade input interface with strong anti-interference capability
Support multiple digital or switch signal inputs
Stable and reliable, suitable for high vibration and high temperature environments of CNC machine tools
Modular rack mounted installation for easy replacement and maintenance
Highly compatible with CNC controllers, with low signal transmission latency
3、 Application Fields
CNC machine tool input module
Used for signal acquisition of CNC equipment such as lathes, milling machines, grinders, etc., to achieve input of switch, limit, and sensor signals.
Automated production line control system
As an input module, it sends detection signals from sensors, photoelectric switches, etc. to the central control system to ensure the automated operation of the production process.
Industrial Robot System
Receive signals such as the position, limit, and workpiece positioning of the robotic arm, and cooperate with the controller to complete precise actions.
Special equipment control system
Used for input signal acquisition and transmission in turntables, machining centers, and special-purpose machinery.
4、 Product advantages
Stable signal acquisition and reduced misoperation
Industrial grade protection, adaptable to harsh environments
Compatible with multiple industrial control systems
Modular structure, easy to maintain and replace
2.产 品 展 示
