Magnetek 1995-A-6M-X 显示面板 PDF资料
1.产 品 资 料 介 绍：
产品概述
MAGNETEK 1995-A-6M-X 是一款用于工业驱动系统的专用显示与操作面板，通常用于 Magnetek 系列变频器或驱动器的前端界面，用于显示运行状态、调整参数、诊断故障以及控制启停。该面板具有直观的人机交互功能，是工业控制系统中的关键辅助组件。
产品特点
实时数据显示
能清晰显示电机运行状态，包括频率、电流、电压、故障代码等。参数设定与调试功能
允许用户浏览和修改驱动器内部参数，便于系统配置和维护。菜单式界面操作
多功能按键布局，操作逻辑清晰，适合现场技术人员使用。故障诊断支持
可快速读取故障代码及报警信息，提高维护效率。适配性强
通常与 GPD503、GPD506、GPD515、CIMR-G5 等 Magnetek 驱动系列兼容。可安装于控制柜门板或驱动器本体
支持远程面板安装方式（通过延长线连接），提升操作便利性。
应用领域
起重机控制系统
现场快速调整电机运行参数与读取运行状态。自动化设备控制面板
用于工控柜中作为操作和监视界面，便于操作人员干预。输送系统
实现本地频率调节和状态监视，提高运行效率。冶金、采矿与重工机械
在高负载现场环境中提供稳定的操作反馈界面。风机、水泵和压缩机系统
作为变频器的本地操作单元，进行频率设定与启动控制。
英文资料：
product overview
MAGNETEK 1995-A-6M-X is a specialized display and operation panel for industrial drive systems, typically used in the front-end interface of Magnetek series inverters or drives to display operating status, adjust parameters, diagnose faults, and control start stop. This panel has intuitive human-computer interaction functions and is a key auxiliary component in industrial control systems.
Product Features
real-time data display
Can clearly display the operating status of the motor, including frequency, current, voltage, fault codes, etc.
Parameter setting and debugging function
Allow users to browse and modify internal parameters of the drive, facilitating system configuration and maintenance.
Menu based interface operation
Multi functional button layout, clear operation logic, suitable for on-site technical personnel to use.
Fault diagnosis support
It can quickly read fault codes and alarm information, improving maintenance efficiency.
Strong adaptability
Usually compatible with Magnetek driver series such as GPD503, GPD506, GPD515, CIMR-G5, etc.
Can be installed on the control cabinet door panel or driver body
Support remote panel installation method (connected through extension cable) to improve operational convenience.
application area
Crane control system
Quickly adjust the motor operating parameters and read the operating status on site.
Automation equipment control panel
Used as an operation and monitoring interface in industrial control cabinets, facilitating operator intervention.
conveying system
Implement local frequency regulation and status monitoring to improve operational efficiency.
Metallurgy, Mining, and Heavy Machinery
Provide a stable operational feedback interface in high load field environments.
Fan, water pump, and compressor system
As the local operating unit of the frequency converter, it is responsible for frequency setting and startup control.
2.产 品 展 示
