Magnetek GPD506VB004变频控制器 PDF资料
1.产 品 资 料 介 绍：
产品概述
Magnetek GPD506VB004 是一款用于三相感应电动机的矢量控制型变频控制器，隶属于 Magnetek GPD506 系列。该型号专为要求高性能驱动、快速响应和稳定控制的工业环境设计，适用于多种重载与精密控制应用。
产品特点
无编码器矢量控制功能
提供接近伺服级别的转矩控制能力，尤其适合低速大转矩应用。高起动转矩能力
即使在低频运行条件下，也能保持较高输出转矩，适应重载起动工况。宽电压输入范围
支持多种工业电源系统，稳定性强。内置制动控制功能（部分版本）
提供快速停车能力，适用于快速响应场合。多种运行控制方式
支持本地控制、远程控制、自动/手动切换等多种模式。丰富的通信与扩展接口
便于与PLC、上位机或其他控制系统集成。内置保护系统
包括过流、过压、过热、欠压、短路保护等，提升运行安全性。
应用领域
起重机与物料搬运设备
控制起升、回转、行走等动作，确保平稳、安全的运行状态。自动化生产线
驱动输送带、装配设备、机器人等，满足对速度、转矩的高精度控制需求。冶金与重工设备
驱动大型电机，实现高功率、高频繁运行条件下的稳定控制。电梯与升降系统
确保启停平稳、定位准确，提升用户体验。风机和水泵控制
实现变速运行，提高能效，延长设备使用寿命。包装、印刷和纺织机械
控制运行节奏与张力，实现高速、高精度加工。
英文资料：
product overview
Magnetek GPD506VB004 is a vector control variable frequency controller for three-phase induction motors, belonging to the Magnetek GPD506 series. This model is designed for industrial environments that require high-performance driving, fast response, and stable control, and is suitable for a variety of heavy-duty and precision control applications.
Product Features
No encoder vector control function
Provide torque control capability close to servo level, especially suitable for low-speed and high torque applications.
High starting torque capability
Even under low-frequency operating conditions, it can maintain a high output torque and adapt to heavy-duty starting conditions.
Wide voltage input range
Supports multiple industrial power systems with strong stability.
Built in brake control function (some versions)
Provide fast parking capability, suitable for quick response situations.
Multiple operation control modes
Supports multiple modes such as local control, remote control, automatic/manual switching, etc.
Rich communication and expansion interfaces
Easy to integrate with PLC, upper computer or other control systems.
Built in protection system
Including overcurrent, overvoltage, overheating, undervoltage, short circuit protection, etc., to enhance operational safety.
application area
Cranes and material handling equipment
Control lifting, turning, walking and other actions to ensure smooth and safe operation.
Automatic production line
Drive conveyor belts, assembly equipment, robots, etc. to meet high-precision control requirements for speed and torque.
Metallurgical and Heavy Industry Equipment
Drive large motors to achieve stable control under high-power and high-frequency operating conditions.
Elevator and lifting system
Ensure smooth start stop and accurate positioning to enhance user experience.
Fan and water pump control
Realize variable speed operation, improve energy efficiency, and extend equipment service life.
Packaging, printing, and textile machinery
Control the running rhythm and tension to achieve high-speed and high-precision machining.
2.产 品 展 示
