Magnetek EDB4040EH动态制动电阻器 PDF资料
1.产 品 资 料 介 绍：
产品概述
MAGNETEK EDB4040EH 是一款工业级动态制动电阻器，专用于变频器和驱动器系统中的能量吸收和消耗。其主要功能是在电机快速减速或制动时，将电机回馈的能量以热能形式释放，从而保护驱动设备和延长系统寿命。
产品特点
高功率吸收能力：能够承受变频器制动过程中的高能量冲击，快速消散回馈能量。
优良的热管理设计：采用耐高温材料和合理散热结构，保证长期稳定运行。
紧凑坚固结构：便于安装于控制柜内，占用空间小，适应工业现场恶劣环境。
多种阻值和功率等级：可根据系统需求选配，满足不同制动要求。
高可靠性和安全性：符合工业标准，具备良好的抗震动和抗冲击性能。
应用领域
变频器驱动系统
广泛应用于交流变频器驱动的风机、水泵、输送机等设备，实现动态制动功能。起重机和搬运设备
用于桥式起重机、门式起重机、龙门吊等快速减速和停止，保护机械安全。冶金与矿山机械
适应高惯量负载的制动需求，保障设备稳定与安全。纺织、印刷和包装机械
保证高速机械在停止时平稳制动，提升生产效率与产品质量。电梯与升降平台
实现平稳制动，提升人员与设备安全。
英文资料：
product overview
MAGNETEK EDB4040EH is an industrial grade dynamic braking resistor designed for energy absorption and consumption in frequency converters and drive systems. Its main function is to release the energy feedback from the motor in the form of thermal energy during rapid deceleration or braking of the motor, thereby protecting the driving equipment and extending the system life.
Product Features
High power absorption capacity: able to withstand high-energy impacts during the braking process of the frequency converter, quickly dissipating feedback energy.
Excellent thermal management design: using high-temperature resistant materials and reasonable heat dissipation structure to ensure long-term stable operation.
Compact and sturdy structure: easy to install inside the control cabinet, occupying small space, suitable for harsh industrial environments.
Multiple resistance values and power levels: can be selected according to system requirements to meet different braking requirements.
High reliability and safety: Complies with industrial standards and has good resistance to vibration and impact.
application area
Variable frequency drive system
Widely used in fans, water pumps, conveyors and other equipment driven by AC frequency converters to achieve dynamic braking function.
Cranes and handling equipment
Used for rapid deceleration and stopping of bridge cranes, gantry cranes, gantry cranes, etc., to protect mechanical safety.
Metallurgy and Mining Machinery
Adapt to the braking requirements of high inertia loads, ensuring equipment stability and safety.
Textile, printing and packaging machinery
Ensure smooth braking of high-speed machinery when stopped, improve production efficiency and product quality.
Elevators and lifting platforms
Realize smooth braking and improve personnel and equipment safety.
