EMERSON FloBoss S600+ 前面板 PDF资料
1.产 品 资 料 介 绍：
产品概述
EMERSON FloBoss S600+ 是一款专为天然气输配和液体流量计量应用而设计的高精度流量计算机，前面板作为其操作与人机交互的界面部分，主要提供本地控制、数据查看、配置和报警响应等功能。S600+ 广泛应用于关键计量点，其前面板具备图形显示、导航按钮、报警指示等特性，是实现现场数据监控与快速操作的重要组成部分。
技术参数（前面板部分简要）
设备名称：FloBoss S600+ 前面板
显示功能：高对比度LCD或图形显示屏
人机界面：带导航键或触控功能（视版本而定）
通信功能：本地配置、数据浏览、警报显示
功能扩展：与主处理单元联动显示流量、状态、报警等信息
安装方式：嵌入式安装于机柜或面板箱体前端
应用场景
天然气计量与调度站
在城市燃气、天然气处理厂、主干管网等关键计量点，提供数据查看、校验与本地操控。
支持 AGA/API 标准的气体体积修正与流量计算。
油气田计量系统
用于原油、天然气或混合气的现场计量站，前面板支持现场参数快速读取与配置确认。
实现远程 SCADA 系统之外的本地诊断与维护操作。
炼油厂与化工厂流量监测
用于液体产品的贸易计量、分配管理，确保过程计量符合法规与商业要求。
前面板便于操作员现场监控关键指标如密度、温度、体积等。
LNG 加注站与液化气配送
应用于LNG接收、再气化和罐车装载过程中的计量控制，前面板帮助本地人员快速确认加注状态。
电厂燃料计量系统
对接入天然气的发电厂，提供高精度流量测量和数据校验，本地前面板便于调试与控制参数配置。
贸易交接站点
前面板作为贸易交接过程中的本地人机界面，支持标准协议认证、参数锁定和报警处理等操作。
英文资料：
product overview
The EMERSON FloBoss S600+is a high-precision flow computer designed specifically for natural gas distribution and liquid flow metering applications. The front panel serves as the interface for its operation and human-machine interaction, providing functions such as local control, data viewing, configuration, and alarm response. S600+is widely used in key measurement points, and its front panel has features such as graphic display, navigation buttons, alarm indicators, etc. It is an important component for achieving on-site data monitoring and rapid operation.
Technical Parameters (Brief Introduction to the Front Panel)
Device Name: FloBoss S600+Front Panel
Display function: High contrast LCD or graphic display screen
Human computer interface: with navigation keys or touch functions (depending on the version)
Communication functions: local configuration, data browsing, alarm display
Function extension: Link with the main processing unit to display information such as traffic, status, alarms, etc
Installation method: Embedded installation at the front end of the cabinet or panel box
Application scenarios
Natural gas metering and dispatch station
Provide data viewing, verification, and local control at key metering points such as urban gas, natural gas processing plants, and main pipeline networks.
Support gas volume correction and flow calculation according to AGA/API standards.
Oil and gas field metering system
Used for on-site metering stations for crude oil, natural gas, or mixed gas, the front panel supports quick reading of on-site parameters and configuration confirmation.
Implement local diagnostic and maintenance operations outside of remote SCADA systems.
Flow monitoring in refineries and chemical plants
Used for trade measurement and distribution management of liquid products, ensuring that process measurement complies with regulatory and commercial requirements.
The front panel facilitates on-site monitoring of key indicators such as density, temperature, volume, etc. by the operator.
LNG refueling station and liquefied gas distribution
Used for metering control during LNG receiving, re gasification, and tanker loading processes, the front panel helps local personnel quickly confirm the refueling status.
Power plant fuel metering system
Provide high-precision flow measurement and data verification for power plants connected to natural gas, with a local front panel for easy debugging and parameter configuration control.
Trade handover station
The front panel serves as the local human-machine interface during the trade handover process, supporting operations such as standard protocol authentication, parameter locking, and alarm processing.
2.产 品 展 示
