Magnetek 46S03289-0010变频器模块 PDF资料
1.产 品 资 料 介 绍：
Magnetek CIMR-V7AM40P41 变速驱动器
产品应用特点：
紧凑型设计
体积小巧，适合空间有限的控制柜安装，尤其适用于OEM设备或小型系统集成项目。精确的速度控制
支持V/F控制模式，实现对交流电机的连续变速调节，满足对速度精度要求较高的应用场合。易于调试与操作
提供直观的参数设置方式，配合内置操作键盘，方便现场快速调试与调整。内置制动晶体功能
可直接接入制动电阻，用于快速制动和提升系统响应速度，无需外接制动单元。多功能输入输出接口
拥有多路可编程的数字输入、继电器输出与模拟输入/输出端口，增强与外部设备的连接与控制能力。电磁兼容性强
符合工业环境的EMC标准，具备良好的抗干扰性能，保障系统稳定运行。过载能力强
具备150%额定电流60秒的过载能力，适合周期性负载变化较大的工况。自动电压调整（AVR）
能在输入电压波动时保持输出电压稳定，保护电机不受电压波动影响。多重安全保护
内设短路、过压、欠压、过热、接地故障等保护机制，保障操作安全和设备寿命。典型应用领域
广泛应用于传送带、风机、水泵、小型机床、包装设备、纺织机械等需变速控制的中轻负载工业场合。
英文资料：
Magnetek CIMR-V7AM40P41 Variable Speed Drive
Product application features:
Compact design
Compact in size, suitable for installation in control cabinets with limited space, especially for OEM equipment or small system integration projects.
Accurate speed control
Support V/F control mode to achieve continuous variable speed regulation of AC motors, meeting the requirements of applications with high speed accuracy.
Easy to debug and operate
Provide intuitive parameter setting methods, combined with a built-in operation keyboard, for easy on-site quick debugging and adjustment.
Built in brake crystal function
It can be directly connected to the braking resistor for fast braking and improving system response speed, without the need for an external braking unit.
Multi functional input/output interface
Having multiple programmable digital inputs, relay outputs, and analog input/output ports enhances connectivity and control capabilities with external devices.
Strong electromagnetic compatibility
Compliant with EMC standards for industrial environments, with excellent anti-interference performance, ensuring stable system operation.
Strong overload capacity
It has an overload capacity of 150% rated current for 60 seconds, suitable for working conditions with large periodic load changes.
Automatic Voltage Regulation (AVR)
Can maintain stable output voltage during input voltage fluctuations, protecting the motor from voltage fluctuations.
Multiple security protections
Equipped with protection mechanisms such as short circuit, overvoltage, undervoltage, overheating, and grounding faults to ensure operational safety and equipment lifespan.
Typical application areas
Widely used in medium and light load industrial applications that require variable speed control, such as conveyor belts, fans, water pumps, small machine tools, packaging equipment, textile machinery, etc.
2.产 品 展 示
