Magnetek 46S02439-0031控制器模块 PDF资料
1.产 品 资 料 介 绍：
产品应用领域：
高功率整流系统
用于控制大型硅控整流（SCR）桥，适用于直流供电、电机调速和工业加热等系统。起重与物料搬运设备
应用于起重机、升降设备中，实现整流单元的电流控制与过载保护。冶金与金属加工行业
安装于轧钢、熔炼等高电流应用场合，调节电压与波形，确保负载稳定性。工业水泵与风机系统
用于控制电源输入，提升系统运行效率并延长电机使用寿命。老旧控制系统维护
被广泛用于替换停产或故障的老型号控制模块，恢复系统功能，降低更换成本。
产品特点：
支持12通道SCR控制
可同时控制多个整流元件，满足高电流场合的控制需求。结构紧凑，易于安装
模块化设计，方便集成进现有电控系统或替换原有部件。工业级可靠性设计
具备良好的抗干扰性和耐高温性能，适应复杂工业环境。电气隔离触发输出
各通道触发信号独立隔离，增强系统安全性与稳定性。兼容性强
可与多种Magnetek和Louis Allis系统配套使用，支持系统扩展或升级。易于维护与更换
标准化接口与清晰标识，便于现场技术人员快速定位与操作。
英文资料：
Product application areas:
High power rectification system
Used for controlling large silicon controlled rectifier (SCR) bridges, suitable for systems such as DC power supply, motor speed regulation, and industrial heating.
Lifting and material handling equipment
Applied in cranes and lifting equipment to achieve current control and overload protection of rectifier units.
Metallurgical and metal processing industry
Installed in high current applications such as steel rolling and melting, regulating voltage and waveform to ensure load stability.
Industrial water pump and fan system
Used to control power input, improve system efficiency, and extend motor lifespan.
Maintenance of old control systems
Widely used to replace outdated or malfunctioning control modules, restore system functionality, and reduce replacement costs.
Product features:
Support 12 channel SCR control
It can simultaneously control multiple rectifying components to meet the control requirements of high current situations.
Compact structure, easy to install
Modular design facilitates integration into existing electrical control systems or replacement of existing components.
Industrial grade reliability design
Has good anti-interference and high temperature resistance, suitable for complex industrial environments.
Electrical isolation triggers output
Each channel triggers independent isolation of signals to enhance system security and stability.
Strong compatibility
Can be used with multiple Magnetek and Louis Allis systems, supporting system expansion or upgrade.
Easy to maintain and replace
Standardized interfaces and clear labeling facilitate quick positioning and operation by on-site technicians.
2.产 品 展 示
