Magnetek EDB4021DT 动态制动电阻器 PDF资料
1.产 品 资 料 介 绍：
Magnetek EDB4021DT 动态制动电阻器 产品应用特点：
高效能量吸收能力
能快速吸收变频器在制动过程中产生的再生能量，防止母线电压过高。耐高温设计
采用耐高温材料和散热结构，适用于高频率、长时间制动工况。结构紧凑，安装灵活
外形设计紧凑，可灵活安装于各类控制柜或设备结构内，节省空间。热稳定性强
优良的热容量设计，确保在连续高负载运行中性能稳定不衰减。防护性能优越
表面具备防腐蚀涂层，适应潮湿、粉尘等复杂工业环境。高绝缘性能
具备良好的电气绝缘特性，确保使用过程中的电气安全。与变频器兼容性好
可与多种品牌和型号的变频器配合使用，提升制动系统的可靠性。适用范围广
适用于起重、电梯、卷扬、输送等频繁启停、快速制动的应用场合。散热效率高
精心设计的散热结构，有效控制运行温升，延长使用寿命。维护简便
模块化结构便于更换和检修，降低维护成本与停机时间。
英文资料：
Magnetek EDB4021DT dynamic braking resistor product application features:
Efficient energy absorption capacity
It can quickly absorb the regenerative energy generated by the frequency converter during the braking process, preventing excessive bus voltage.
High temperature resistant design
Adopting high-temperature resistant materials and heat dissipation structure, suitable for high-frequency and long-term braking conditions.
Compact structure, flexible installation
The compact design allows for flexible installation in various control cabinets or equipment structures, saving space.
Strong thermal stability
Excellent heat capacity design ensures stable performance without degradation during continuous high load operation.
Superior protective performance
The surface has a corrosion-resistant coating, which is suitable for complex industrial environments such as humidity and dust.
high insulating property
Having good electrical insulation properties ensures electrical safety during use.
Good compatibility with frequency converters
Can be used in conjunction with multiple brands and models of frequency converters to enhance the reliability of the braking system.
Wide applicability
Suitable for frequent start stop and rapid braking applications such as lifting, elevators, winches, and conveyors.
High heat dissipation efficiency
Carefully designed heat dissipation structure effectively controls operating temperature rise and extends service life.
Easy to maintain
The modular structure facilitates replacement and maintenance, reducing maintenance costs and downtime.
2.产 品 展 示
