Magnetek GPD506VB003 交流电驱动器 PDF资料
1.产 品 资 料 介 绍：
一、产品概述
型号：GPD506VB003（GPD506V‑B003）
类型：通用型三相交流变频驱动器（AC Drive）
功率等级：约 ½ HP（约 0.37 kW）
电压等级：460 VAC，50/60 Hz 三相输入
额定输出电流：约 3.4 A（部分资料显示 3.6 A）
当前状态：该型号已由制造商停产，现仅作为备件或二手设备流通。
二、典型应用领域
轻载泵与冷却循环设备
适用于小功率水泵、冷却泵或辅助循环系统的转速控制，通过变频调速实现节能控制。
小型风扇与通风设备
用于小型通风机、抽风机等场合，实现启停柔性控制和风量调节。
小型输送与搬运设备
小功率传送带、物料滚筒系统、分拣设备等轻载工业流程，实现速度控制和启停管理。
实验室与测试平台
在研发或工业测试平台上，用于驱动小型电机进行精确频率与速度控制实验。
教学与培训系统
在电气自动化、机电一体化教学中作为演示或实操单元，帮助学员理解变频器基本控制原理。
三、产品优势与适配性
体积小、功率低：适合小型动力需求场合，安装空间要求低，便于集成。
节能控制：通过频率与电压调节实现资源节约和更柔软的设备启动／停止过程。
用户可编程：尽管属于较早型号，但支持基本参数设定与启动逻辑编程。
维护经济：维修或替换成本较低，适合预算有限的小规模应用。
英文资料：
1、 Product Overview
Model: GPD506VB003 (GPD506V-B003)
Type: Universal three-phase AC variable frequency drive (AC Drive)
Power level: Approximately 1/2 HP (approximately 0.37 kW)
Voltage level: 460 VAC, 50/60 Hz three-phase input
Rated output current: approximately 3.4 A (some data shows 3.6 A)
Current status: This model has been discontinued by the manufacturer and is currently only in circulation as a spare part or used equipment.
2、 Typical application areas
Light load pump and cooling circulation equipment
Suitable for speed control of low-power water pumps, cooling pumps, or auxiliary circulation systems, energy-saving control is achieved through variable frequency speed regulation.
Small fans and ventilation equipment
Used for small ventilation fans, exhaust fans, and other occasions to achieve flexible control of start stop and air volume adjustment.
Small conveying and handling equipment
Low power conveyor belts, material drum systems, sorting equipment, and other light-duty industrial processes achieve speed control and start stop management.
Laboratory and Testing Platform
Used to drive small motors for precise frequency and speed control experiments on research and development or industrial testing platforms.
Teaching and Training System
As a demonstration or practical unit in the teaching of electrical automation and mechatronics, it helps students understand the basic control principles of frequency converters.
3、 Product advantages and adaptability
Small size and low power: suitable for small power demand occasions, with low installation space requirements and easy integration.
Energy saving control: achieve resource conservation and softer equipment start/stop processes through frequency and voltage regulation.
User programmable: Despite being an earlier model, it supports basic parameter settings and startup logic programming.
Maintaining economy: Low maintenance or replacement costs, suitable for small-scale applications with limited budgets.
2.产 品 展 示
