Magnetek GPD506V-B041变频驱动器 PDF资料
1.产 品 资 料 介 绍：
MAGNETEK GPD506V-B041 变频驱动器
一、产品概述
类型：通用型交流变频驱动器
电源输入：三相 380–480V AC
额定功率：约 22kW（30HP）
输出电流：最大约 41A
控制方式：支持V/F控制和矢量控制
频率范围：0.1Hz 至 400Hz
冷却方式：强制风冷
二、产品特点
高性能矢量控制，适用于需要精确调速和稳定性的场合
快速响应的过载保护和故障自诊断功能
内置数字和模拟输入/输出端口，便于控制系统集成
支持通讯扩展模块（如Modbus）
多种运行模式可选：恒转矩、变量转矩等
面板操作简便，支持参数复制与快速调试
模块化结构，维护更方便
三、典型应用领域
起重设备：桥式起重机、电动葫芦
水泵风机：工业通风与水处理系统
输送设备：自动化输送线、包装机械
加工设备：数控机床、塑料机械、绕线机等
英文资料：
MAGNETEK GPD506V-B041 Variable Frequency Drive
1、 Product Overview
Type: Universal AC Variable Frequency Drive
Power input: three-phase 380-480V AC
Rated power: approximately 22kW (30HP)
Output current: Approximately 41A at most
Control mode: Supports V/F control and vector control
Frequency range: 0.1Hz to 400Hz
Cooling method: forced air cooling
2、 Product Features
High performance vector control, suitable for situations that require precise speed regulation and stability
Quick response overload protection and fault self diagnosis function
Built in digital and analog input/output ports for easy control system integration
Support communication expansion modules (such as Modbus)
Multiple operating modes to choose from: constant torque, variable torque, etc
Easy to operate panel, supports parameter copying and quick debugging
Modular structure for easier maintenance
3、 Typical application areas
Lifting equipment: bridge crane, electric hoist
Pump Fan: Industrial Ventilation and Water Treatment System
Conveyor equipment: automated conveyor lines, packaging machinery
Processing equipment: CNC machine tools, plastic machinery, winding machines, etc
2.产 品 展 示
