Magnetek 46S03331-1260动态制动模块 PDF资料
1.产 品 资 料 介 绍：
MAGNETEK 46S03331-1260 动态制动模块
一、产品概述
型号：46S03331-1260
类型：动态制动模块
适用电压：460V AC
额定电流容量：18A
主要功能为对交流电机实现快速制动及能量回馈
该产品已停产
二、主要功能
快速降低电机转速，缩短制动时间，适合频繁启动停止场合
将电机再生能量转换为热能，通过制动电阻释放，防止驱动器过电压
保护驱动器免受电压过高造成的跳闸或故障
三、典型应用领域
起重机及吊装设备的电机快速制动
输送设备的启停控制
自动化生产线中的快速响应控制
电梯及升降平台的安全制动
四、产品优势
有效管理电机再生能量，保障系统稳定
增强设备运行安全性和可靠性
适用范围广，兼容多种工业自动化设备
英文资料：
MAGNETEK 46S03331-1260 Dynamic Braking Module
1、 Product Overview
Model: 46S03331-1260
Type: Dynamic Braking Module
Applicable voltage: 460V AC
Rated current capacity: 18A
The main function is to achieve fast braking and energy feedback for AC motors
This product has been discontinued
2、 Main functions
Quickly reduce motor speed, shorten braking time, suitable for frequent starting and stopping situations
Convert the regenerative energy of the motor into thermal energy, release it through the braking resistor, and prevent overvoltage of the driver
Protect the driver from tripping or faults caused by high voltage
3、 Typical application areas
Fast braking of motors for cranes and lifting equipment
Start stop control of conveying equipment
Rapid response control in automated production lines
Safety braking of elevators and lifting platforms
4、 Product advantages
Effective management of motor regeneration energy to ensure system stability
Enhance the safety and reliability of equipment operation
Widely applicable and compatible with various industrial automation equipment
2.产 品 展 示
