Magnetek GPD505V-B011交流电驱动器 PDF资料
1.产 品 资 料 介 绍：
MAGNETEK GPD505V-B011 交流电驱动器
一、产品概述
型号：GPD505V-B011
系列：GPD505V 系列通用型变频驱动器
输入电压：三相 380–480V AC
输出电流：约 11A
额定功率：7.5 HP（约 5.6 kW）
控制方式：V/f 控制（电压/频率比控制）
适用电机：三相感应电机
二、产品特点
成熟稳定的 V/f 控制技术
适合风机、水泵等变转矩负载
提供稳定的低速输出能力
较强的过载能力
150% 电流持续 1 分钟
适应负载波动较大的场景
多功能数字/模拟输入输出接口
多路可编程数字输入：支持启停、正反转、故障复位等
模拟输入支持 0–10V 或 4–20mA：用于频率或速度控制
继电器输出可用作运行指示、故障报警等
完善的保护机制
内置过压、过流、欠压、过热、短路等多重保护
故障代码显示便于现场快速诊断
紧凑设计、易于集成
模块体积小，重量轻，便于安装在控制柜内
风冷设计，适用于密闭或通风良好的电控箱
维护便捷
参数设置简洁，支持面板调试或复制
易于替换维修，适合工业环境下长期使用
英文资料：
MAGNETEK GPD505V-B011 AC Driver
1、 Product Overview
Model: GPD505V-B011
Series: GPD505V Series Universal Variable Frequency Drive
Input voltage: three-phase 380-480V AC
Output current: approximately 11A
Rated power: 7.5 HP (approximately 5.6 kW)
Control mode: V/f control (voltage/frequency ratio control)
Applicable motor: three-phase induction motor
2、 Product Features
Mature and stable V/f control technology
Suitable for variable torque loads such as fans and pumps
Provide stable low-speed output capability
Strong overload capacity
150% current for 1 minute
Adapt to scenarios with significant load fluctuations
Multi functional digital/analog input/output interface
Multi channel programmable digital input: supports start stop, forward and reverse rotation, fault reset, etc
Analog input supports 0-10V or 4-20mA: used for frequency or speed control
Relay output can be used for operation indication, fault alarm, etc
A comprehensive protection mechanism
Built in multiple protections such as overvoltage, overcurrent, undervoltage, overheating, and short circuit
Fault code display facilitates quick on-site diagnosis
Compact design, easy to integrate
The module has a small volume and light weight, making it easy to install inside the control cabinet
Air cooled design, suitable for enclosed or well ventilated electrical control boxes
Convenient maintenance
Simple parameter settings, supporting panel debugging or copying
Easy to replace and repair, suitable for long-term use in industrial environments
