1.产 品 资 料 介 绍：
MAGNETEK CIMR-F7U45P5 可调频驱动器
一、产品概述
CIMR-F7U45P5 属于三菱（Mitsubishi）F7系列变频驱动器，由 Magnetek 代理或销售，专为中功率工业电机调速设计。该驱动器适合多种应用场合，支持高性能矢量控制，能提供稳定、高效的速度和转矩控制。
二、技术规格
额定功率：约 45 kW（约 60 HP）
输入电压：三相 380–480 VAC
输出频率范围：0.1 Hz 至 400 Hz
控制方式：无传感器矢量控制（Sensorless Vector Control）与 V/f 控制
过载能力：150% 额定电流，持续 1 分钟
冷却方式：强制风冷
三、产品特点
高性能矢量控制
实现无编码器的精确转矩和速度控制
适用于高动态响应场合
多种控制模式
支持 V/f 控制和无传感器矢量控制，满足不同负载需求
保护功能全面
内置过载、过压、欠压、过热、短路等多重保护
故障自动诊断，便于维护
丰富的接口
多路数字/模拟输入输出，灵活配置控制逻辑
支持多种工业通讯协议（可选模块）
易于调试与维护
提供数字操作面板，参数设置直观方便
支持参数存储与快速复制
英文资料：
MAGNETEK CIMR-F7U45P5 Adjustable Frequency Driver
1、 Product Overview
CIMR-F7U45P5 belongs to the Mitsubishi F7 series variable frequency drive, represented or sold by Magnetek, specifically designed for medium power industrial motor speed regulation. This driver is suitable for various application scenarios, supports high-performance vector control, and can provide stable and efficient speed and torque control.
2、 Technical specifications
Rated power: approximately 45 kW (approximately 60 HP)
Input voltage: three-phase 380-480 VAC
Output frequency range: 0.1 Hz to 400 Hz
Control methods: Sensorless Vector Control and V/f Control
Overload capacity: 150% rated current, lasting for 1 minute
Cooling method: forced air cooling
3、 Product Features
High performance vector control
Realize precise torque and speed control without encoder
Suitable for high dynamic response scenarios
Multiple control modes
Support V/f control and sensorless vector control to meet different load requirements
Comprehensive protection function
Built in multiple protections for overload, overvoltage, undervoltage, overheating, short circuit, etc
Automatic fault diagnosis for easy maintenance
Rich interfaces
Multi channel digital/analog input/output, flexible configuration of control logic
Supports multiple industrial communication protocols (optional modules)
Easy to debug and maintain
Provide a digital operation panel with intuitive and convenient parameter settings
Support parameter storage and fast replication
2.产 品 展 示
