MAGNETEK CIMR-G5M4045 驱动器 — 起重机应用简介
一、产品概述
CIMR-G5M4045 是三菱（Mitsubishi）G5系列的一款变频驱动器，Magnetek 作为经销商或代理时常见此型号。该驱动器以其稳定的性能和高可靠性，在起重机和重载工业设备的电机控制领域得到广泛应用。
二、驱动器基本规格
额定功率：约 45 kW（60 HP）
输入电压：三相 380~480 VAC
控制方式：矢量控制（无传感器矢量控制）和 V/f 控制
过载能力：150% 额定电流，持续 1 分钟
频率范围：0.1 Hz 至 400 Hz
冷却方式：强制风冷
三、起重机驱动典型应用功能
提升控制
精准调节电机速度，确保起重机吊钩平稳起升和下降
支持软启动、软停止，减少机械冲击和提升设备寿命
行走控制
控制起重机车轮驱动电机的速度和方向，保证移动平稳
实现多速段控制，适应不同运行工况
横移与旋转控制
多轴协调控制，保证起重机吊具精准定位
支持同步控制，减少振动和机械磨损
安全保护功能
过流、过压、欠压、过热及短路保护
故障诊断与报警，保障系统安全稳定运行
通讯与集成
可与 PLC、工控系统集成，通过 Modbus 或其他工业通讯协议实现远程监控和控制
支持与操作面板联动，实现现场与远程操作无缝切换
英文资料：
MAGNETEK CIMR-G5M4045 Driver - Introduction to Crane Applications
1、 Product Overview
CIMR-G5M4045 is a variable frequency drive from Mitsubishi G5 series, which Magnetek often sees as a distributor or agent. This driver is widely used in the field of motor control for cranes and heavy-duty industrial equipment due to its stable performance and high reliability.
2、 Basic specifications of the driver
Rated power: approximately 45 kW (60 HP)
Input voltage: three-phase 380~480 VAC
Control methods: vector control (sensorless vector control) and V/f control
Overload capacity: 150% rated current, lasting for 1 minute
Frequency range: 0.1 Hz to 400 Hz
Cooling method: forced air cooling
3、 Typical application functions of crane drive
Enhance control
Accurately adjust the motor speed to ensure smooth lifting and lowering of the crane hook
Support soft start and soft stop, reduce mechanical impact and improve equipment lifespan
Walking control
Control the speed and direction of the crane wheel drive motor to ensure smooth movement
Realize multi speed control to adapt to different operating conditions
Lateral and rotational control
Multi axis coordinated control ensures precise positioning of crane lifting equipment
Support synchronous control to reduce vibration and mechanical wear
Safety protection function
Overcurrent, overvoltage, undervoltage, overheating, and short circuit protection
Fault diagnosis and alarm to ensure the safe and stable operation of the system
Communication and Integration
Can be integrated with PLC and industrial control systems, and achieve remote monitoring and control through Modbus or other industrial communication protocols
Support linkage with the operation panel to achieve seamless switching between on-site and remote operations
