Magnetek GPD506V-B096驱动器 PDF资料
1.产 品 资 料 介 绍：
MAGNETEK GPD506V-B096 驱动器
产品类型：三相交流变频器（AC Drive）
系列：GPD506V
额定输出：96 HP（约 71.5 kW）
电压等级：460V 级（三相 380–480 VAC）
一、产品定位与用途
GPD506V-B096 属于 Magnetek GPD506V 高性能工业变频器系列，专为大型感应电机的速度与转矩控制而设计，适用于重载场合，尤其在要求高可靠性与高过载能力的自动化系统中表现优异。
二、主要技术参数
| 项目 | 规格 |
|---|---|
| 输入电压 | 三相 380–480 VAC ±10% |
| 输出功率 | 96 HP（71.5 kW） |
| 输出频率范围 | 0.1–400 Hz |
| 控制方式 | V/f 控制（可编程曲线） |
| 过载能力 | 150% 额定电流，持续 1 分钟 |
| 冷却方式 | 强制风冷（带独立风扇） |
| 防护等级 | 通常为 IP20（需确认外壳） |
| 安装方式 | 控制柜内嵌式或壁挂式 |
三、产品核心特点
1. 高功率驱动能力
可稳定驱动 70kW 以上大功率感应电机
支持高惯量负载，适用于工业重工场合（如起重、混合、压缩）
2. 灵活的 V/f 控制功能
可设定多种电压-频率特性曲线（线性、平方、用户自定义）
提供滑差补偿与跳频带设定，确保稳定运行与避振
3. 强大的保护与诊断机制
内建过压、欠压、过热、过流、接地、瞬停等保护
故障代码显示与日志记录功能，便于快速维护和排查问题
4. 多功能 I/O 接口
支持多个可编程数字输入输出（DI/DO）
提供模拟输入输出（AI/AO）用于速度、电流反馈控制
支持连接外部操作面板与远程控制站
5. 通信与扩展功能
可选配通信模块（如 Modbus、Profibus、DeviceNet）
可与 PLC、HMI 系统无缝集成，便于纳入工业控制网络
英文资料：
MAGNETEK GPD506V-B096 Driver
Product Type: Three phase AC Drive
Series: GPD506V
Rated output: 96 HP (approximately 71.5 kW)
Voltage level: 460V level (three-phase 380-480 VAC)
1、 Product positioning and purpose
GPD506V-B096 belongs to the Magnetek GPD506V high-performance industrial frequency converter series, designed specifically for speed and torque control of large induction motors. It is suitable for heavy-duty applications and performs exceptionally well in automation systems that require high reliability and overload capacity.
2、 Main technical parameters
Project specifications
Input voltage three-phase 380-480 VAC ± 10%
Output power 96 HP (71.5 kW)
Output frequency range 0.1-400 Hz
Control mode V/f control (programmable curve)
Overload capacity of 150% rated current, lasting for 1 minute
Cooling method: forced air cooling (with independent fan)
The protection level is usually IP20 (shell needs to be confirmed)
Installation method: Control cabinet embedded or wall mounted
3、 Core features of the product
1. High power driving capability
Can stably drive high-power induction motors above 70kW
Supports high inertia loads, suitable for industrial heavy industry applications such as lifting, mixing, and compression
2. Flexible V/f control function
Multiple voltage frequency characteristic curves can be set (linear, square, user-defined)
Provide slip compensation and frequency hopping band settings to ensure stable operation and vibration isolation
3. Powerful protection and diagnostic mechanisms
Built in overvoltage, undervoltage, overheating, overcurrent, grounding, instantaneous stop and other protections
Fault code display and logging function for quick maintenance and troubleshooting
4. Multi functional I/O interface
Supports multiple programmable digital inputs and outputs (DI/DO)
Provide analog input/output (AI/AO) for speed and current feedback control
Support connecting external operation panels and remote control stations
5. Communication and Expansion Functions
Optional communication modules (such as Modbus, Profibus, DeviceNet)
Seamless integration with PLC and HMI systems for easy integration into industrial control networks
2.产 品 展 示
