Magnetek 1995-A-6D-P-X 控制面板模块 PDF资料
1.产 品 资 料 介 绍：
一、产品概述
MAGNETEK 1995-A-6D-P-X 是一款用于工业电机控制系统中的 控制面板模块，通常集成于变频器（如 GPD、IMPULSE、VFD 系列）或电动葫芦控制系统中。该模块具备人机界面功能，提供基本的本地控制、状态显示与参数设定接口。
此型号一般表示：
6D：带 6 位数字显示器（如 7 段 LED）
P：具有编程功能（Programming）
X：可能代表特定面板安装类型或定制接口配置
二、主要产品特点
1. 数字显示功能
集成 6 位数码 LED 显示屏，用于实时显示运行状态、故障代码、频率、电流、电压等关键运行参数
显示直观，便于本地操作人员快速识别系统状态
2. 参数设定与查询功能
可进行参数设定、保存与复制，用于变频器初始化或多台驱动器批量配置
支持基本运行参数调整（如频率设定、加减速时间、限流、保护参数）
3. 本地手动控制接口
搭载按键功能（RUN、STOP、UP、DOWN、RESET 等），可直接控制驱动器启停与频率调节
在调试、维护或无上位系统时可临时作为主控面板使用
4. 面板安装兼容性
模块化设计，支持嵌入式或面板前装方式
提供专用连接接口（如排线、插针或多芯连接线）以便于与主控制板或驱动器控制端通信
5. 可用于多个系列兼容驱动器
常见于 MAGNETEK 的 GPD503、GPD505、IMPULSE-G+、IMPULSE VG+、VGX 等系列
也可能在定制电动葫芦控制系统、桥式起重机控制箱等设备中作为本地面板
英文资料：
1、 Product Overview
MAGNETEK 1995-A-6D-P-X is a control panel module used in industrial motor control systems, typically integrated into frequency converters (such as GPD, IMPULSE, VFD series) or electric hoist control systems. This module has human-machine interface functions, providing basic local control, status display, and parameter setting interfaces.
This model generally represents:
6D: Equipped with a 6-digit digital display (such as 7-segment LED)
P: Having programming functionality
X: May represent specific panel installation types or customized interface configurations
2、 Main product features
1. Digital display function
Integrated 6-digit digital LED display screen, used for real-time display of key operating parameters such as operating status, fault codes, frequency, current, voltage, etc
Intuitive display, easy for local operators to quickly identify system status
2. Parameter setting and query function
Parameter setting, saving, and copying can be performed for frequency converter initialization or batch configuration of multiple drives
Support basic operating parameter adjustment (such as frequency setting, acceleration/deceleration time, current limiting, protection parameters)
3. Local manual control interface
Equipped with button functions (RUN, STOP, UP, DOWN, RESET, etc.), it can directly control the start stop and frequency adjustment of the driver
Can be temporarily used as the main control panel during debugging, maintenance, or when there is no upper system
4. Compatibility of panel installation
Modular design, supporting embedded or panel front mounting methods
Provide dedicated connection interfaces (such as ribbon cables, pins, or multi-core cables) for communication with the main control board or driver control terminal
5. Can be used for multiple series of compatible drives
Commonly seen in MAGNETEK's GPD503, GPD505, IMPULSE-G+, IMPULSE VG+, VGX and other series
It may also be used as a local panel in customized electric hoist control systems, bridge crane control boxes, and other equipment
2.产 品 展 示
