Magnetek PSC500电源系统控制器卡 PDF资料
1.产 品 资 料 介 绍：
一、产品概述
Magnetek PSC500 是一款专为工业和商业电源系统设计的 电源系统控制器卡。它通常用于对电源转换设备（如整流器、逆变器、电池充电系统）进行集中管理和智能控制。该控制卡具备高级电源监控、系统状态诊断、通信接口管理、数据记录与告警功能，在整个电力电子控制系统中扮演核心调度角色。
二、典型应用领域
1. 工业不间断电源系统（UPS）
管理 UPS 中的整流器、逆变器及电池充电单元，确保稳定输出电压
在电网断电或电压波动时快速切换至电池供电，保障关键负载持续运行
对温度、电流、电压等进行监控，实现系统自我保护
2. 直流电源系统管理（DC Power Plants）
常用于通信基站、数据中心、铁路信号系统等直流供电场景
控制整流模块的启停与均流，保持输出稳定
管理电池组充电状态，提供均衡充电、防过放控制
3. 通信与网络基础设施
管理通信机房的多模块整流器系统
支持远程监控与网络通信，确保供电系统冗余运行
提供掉电告警、远程断电、均流保护等功能
4. 轨道交通与地铁供电系统
监控 DC 轨道供电系统中的整流器及备用电源状态
实现系统报警、过载限制、电池自动切换等操作
可集成入列车通信网络或 SCADA 系统进行统一管理
5. 能源与电力自动化系统
用于控制光伏/风电/储能等混合能源系统中的功率变换单元
协调并网逆变器、直流母线与蓄电池充放电控制
提供系统故障诊断和远程控制能力
6. 医疗与精密设备供电保障
医疗设备中的稳定电源控制，防止瞬时断电对设备造成损害
实时监控各电源模块的运行状态，快速响应异常情况
英文资料：
1、 Product Overview
Magnetek PSC500 is a power system controller card designed specifically for industrial and commercial power systems. It is commonly used for centralized management and intelligent control of power conversion equipment such as rectifiers, inverters, and battery charging systems. This control card has advanced power monitoring, system status diagnosis, communication interface management, data recording and alarm functions, and plays a core scheduling role in the entire power electronic control system.
2、 Typical application areas
1. Industrial uninterruptible power supply system (UPS)
Manage rectifiers, inverters, and battery charging units in UPS to ensure stable output voltage
Quickly switch to battery power supply during power outages or voltage fluctuations to ensure continuous operation of critical loads
Monitor temperature, current, voltage, etc. to achieve system self-protection
2. Management of DC Power Plants
Commonly used in DC power supply scenarios such as communication base stations, data centers, railway signal systems, etc
Control the start stop and current sharing of the rectifier module to maintain stable output
Manage the charging status of the battery pack, provide balanced charging, and prevent over discharge control
3. Communication and network infrastructure
Multi module rectifier system for managing communication rooms
Support remote monitoring and network communication to ensure redundant operation of the power supply system
Provide functions such as power failure alarm, remote power-off, and current sharing protection
4. Rail transit and subway power supply system
Monitor the status of rectifiers and backup power sources in the DC rail power supply system
Implement system alarm, overload limit, automatic battery switching and other operations
Can be integrated into the train communication network or SCADA system for unified management
5. Energy and Power Automation System
Used to control power conversion units in hybrid energy systems such as photovoltaic/wind power/energy storage
Coordinate grid connected inverters, DC busbars, and battery charging and discharging control
Provide system fault diagnosis and remote control capabilities
6. Power supply guarantee for medical and precision equipment
Stable power control in medical equipment to prevent damage caused by instantaneous power outages
Real time monitoring of the operating status of each power module and quick response to abnormal situations
