Magnetek GPD505V-B034 逆变器 PDF资料
1.产 品 资 料 介 绍：
一、产品概述
Magnetek GPD505V-B034 是 GPD 505V 系列的一款三相交流变频逆变器（Inverter），适用于 460V 电压等级的工业驱动应用，输出功率为 34 HP（马力）。该型号主要用于控制三相感应电动机的转速、转矩和方向，通过变频技术实现高效节能和精密控制。
二、技术规格（典型）
输入电压：三相 380~460 VAC，50/60 Hz
输出电压：0~460 VAC，变频输出
功率等级：34 HP（约 25.3 kW）
输出频率范围：0.1~400 Hz
控制方式：V/f（电压/频率）控制或矢量控制
过载能力：150% 额定电流，持续 60 秒
冷却方式：强制风冷
通讯接口：支持扩展卡（如 RS-485、DeviceNet 等）
三、主要产品特点
1. 先进的矢量控制技术
实现对电机转矩和速度的精确控制，尤其适用于高动态响应场合。
提供无传感器矢量控制（Sensorless Vector），无需编码器即可获得稳定转矩输出。
2. 宽广的频率输出范围
输出频率可达 400 Hz，适用于高速电机与特殊应用需求。
3. 丰富的保护功能
内置过压、欠压、过流、过热、接地短路等故障检测与保护机制。
自动复位与可编程故障响应机制可提升系统可用性。
4. 易于设置与调试
提供数字操作面板，支持参数查看、修改与存储。
参数结构清晰，具备快捷复制功能，适合批量调试。
5. 灵活的I/O配置
多达 5 个数字输入、2 个模拟输入、2 个继电器输出及1个模拟输出。
所有 I/O 可通过参数进行功能映射，实现定制控制逻辑。
6. 内置节能运行模式
在轻负载时自动降低输出电压，降低能耗。
支持跳跃频率带（避开共振）与动态制动控制。
7. 模块化设计，便于维护
风扇、控制板等部件可独立更换，简化维修过程。
支持热插拔式通讯模块。
英文资料：
1、 Product Overview
Magnetek GPD505V-B034 is a three-phase AC inverter in the GPD 505V series, suitable for industrial drive applications at 460V voltage level, with an output power of 34 HP (horsepower). This model is mainly used to control the speed, torque, and direction of three-phase induction motors, achieving high efficiency, energy saving, and precision control through frequency conversion technology.
2、 Technical specifications (typical)
Input voltage: three-phase 380~460 VAC, 50/60 Hz
Output voltage: 0~460 VAC, variable frequency output
Power level: 34 HP (approximately 25.3 kW)
Output frequency range: 0.1~400 Hz
Control mode: V/f (voltage/frequency) control or vector control
Overload capacity: 150% rated current, lasting for 60 seconds
Cooling method: forced air cooling
Communication interface: Supports expansion cards (such as RS-485, DeviceNet, etc.)
3、 Main product features
1. Advanced vector control technology
Realize precise control of motor torque and speed, especially suitable for high dynamic response scenarios.
Provide sensorless vector control to achieve stable torque output without the need for an encoder.
2. Wide frequency output range
The output frequency can reach 400 Hz, suitable for high-speed motors and special application requirements.
3. Rich protection functions
Built in fault detection and protection mechanisms for overvoltage, undervoltage, overcurrent, overheating, and ground short circuit.
Automatic reset and programmable fault response mechanisms can improve system availability.
4. Easy to set up and debug
Provide a digital operation panel that supports parameter viewing, modification, and storage.
The parameter structure is clear, with quick copying function, suitable for batch debugging.
5. Flexible I/O configuration
Up to 5 digital inputs, 2 analog inputs, 2 relay outputs, and 1 analog output.
All I/O can be functionally mapped through parameters to achieve customized control logic.
6. Built in energy-saving operation mode
Automatically reduce output voltage during light load to lower energy consumption.
Support jumping frequency band (avoiding resonance) and dynamic braking control.
7. Modular design for easy maintenance
Fans, control boards, and other components can be replaced independently, simplifying the maintenance process.
Support hot swappable communication modules.
