Magnetek GPD503-DS308交流电驱动器 PDF资料

1.产 品 资 料 介 绍：

MAGNETEK GPD503-DS308 交流电驱动器

产品特点

1. 高性能 V/f 控制技术

• 采用稳定的电压/频率比例控制，适合一般工业负载，如风机、水泵、输送设备；

• 支持可调 V/f 曲线，便于优化低速性能或特定负载响应。

2. 宽范围电压输入与输出适应性

• 支持多种电源输入（常见为三相380–460V），适配性强；

• 输出频率范围广（通常可达0.1~400Hz），满足不同速度控制需求。

3. 软启动 / 停机功能

• 内建加减速时间可调逻辑，有效减少启动冲击、降低机械磨损；

• 可在停电或故障时实现平稳断电保护。

4. 故障自诊断与安全保护机制

• 提供过电压、欠电压、过电流、过热、输出短路等多重保护；

• 内置故障记录和显示功能，便于维护人员定位问题。

5. 用户参数设置简便

• 数字操作面板设计清晰，参数设定逻辑合理；

• 支持参数复制功能，适合批量调试与备份恢复。

6. 结构坚固，工业适应性强

• 封装稳固，防尘耐热，适用于高温、多尘等复杂工况；

• 适合控制柜内部或壁挂式安装，现场部署灵活。

7. 兼容性良好

• 可与多种常规三相感应电机兼容，无需特殊调整；

• 输入输出端子支持常见数字量与模拟量控制，便于与PLC、按钮站、传感器等设备集成

英文资料：

MAGNETEK GPD503-DS308 AC Driver

Product Features

High performance V/f control technology

Adopting stable voltage/frequency ratio control, suitable for general industrial loads such as fans, water pumps, and conveying equipment;

Support adjustable V/f curves for optimizing low-speed performance or specific load response.

Wide range voltage input and output adaptability

Supports multiple power inputs (commonly three-phase 380-460V), with strong adaptability;

The output frequency range is wide (usually up to 0.1-400Hz), meeting different speed control requirements.

Soft start/stop function

Built in adjustable acceleration and deceleration time logic, effectively reducing startup impact and mechanical wear;

Smooth power-off protection can be achieved during power outages or malfunctions.

Fault self diagnosis and safety protection mechanism

Provide multiple protections such as overvoltage, undervoltage, overcurrent, overheating, and output short circuit;

Built in fault recording and display function, making it easy for maintenance personnel to locate problems.

Easy to set user parameters

The digital operation panel design is clear and the parameter setting logic is reasonable;

Support parameter copying function, suitable for batch debugging and backup recovery.

Sturdy structure and strong industrial adaptability

Stable packaging, dustproof and heat-resistant, suitable for complex working conditions such as high temperature and high dust;

Suitable for installation inside control cabinets or wall mounted, with flexible on-site deployment.

Good compatibility

Compatible with various conventional three-phase induction motors without the need for special adjustments;

The input and output terminals support common digital and analog control, making it easy to integrate with devices such as PLCs, button stations, sensors, etc

2.产      品      展      示
